Setting up a Snom DECT Base of the M-Series on a FritzBox
Introduction

1) Connecting FritzBox to DSL

Connecting FritzBox to DSL via DSL adapter
2) Setting up Internet access
3) Setting up Snom IP-Phone
3.1) Step by step instructions - FritzBox:
3.2 Step by step guide - Snom DECT base:
Configure server:
Configuring an extension
Setting up Telekom SIP trunk (FritzBox)
Related articles
Introduction
To anticipate this, a FritzBox can easily act as a SIP Registrar.
This article is based on a test on a FritzBox 7390 or 7590. It was tested on a Telekom All-IP connection.
1) Connecting FritzBox to DSL
The cables and adapters supplied with the FritzBox differ depending on the product variant. Therefore, take the cabling according to the scope of delivery
of your FritzBox as in one of the two following sections described above.
Connect FritzBox to DSL via DSL cable (TAE/RJ45)
1.
Plug the RJ45 plug of the DSL cable into the "
2.
Plug the TAE plug of the DSL cable into the socket of the TAE socket labeled " " (see Fig. 1).
Connecting FritzBox to DSL via DSL adapter
1.
Plug the long end of the DSL/telephone cable into the "
2.
Insert the short grey cable end into the grey DSL adapter.
3.
Plug the DSL adapter into the socket of the TAE socket labeled " ".
4.
Leave the black cable end free (see illustration).
2) Setting up Internet access
DSL/TEL
" socket of the FritzBox.
DSL(/TEL)
" socket of the FritzBox.
F
F

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M Series and is the answer not in the manual?

Questions and answers

Related Manuals for Snom M Series

Summary of Contents for Snom M Series

  • Page 1 Setting up a Snom DECT Base of the M-Series on a FritzBox Introduction 1) Connecting FritzBox to DSL Connecting FritzBox to DSL via DSL adapter 2) Setting up Internet access 3) Setting up Snom IP-Phone 3.1) Step by step instructions - FritzBox: 3.2 Step by step guide - Snom DECT base:...
  • Page 2 Afterwards you will find your access data under the menu item: Internet/Access data 3) Setting up Snom IP-Phone The configuration of the Snom phone on the FritzBox is relatively simple. First you have to create a new telephony device in the FritzBox -...
  • Page 3 user name password are important here. The user name should have at least 8 characters. AVM changed the password rules. Now it has to be more safe. And it is no longer important how long it is, but i should have a combi nation of lower and upper case letters numbers special characters as usual.
  • Page 4 Next select the item: " LAN/WAN (IP phone) ". Name the new phone with a unique name. Then click on " Next " again. Now assign a " user name " and a " password ". (The assigned phone number can also be used as user name if you want.) Then click on "...
  • Page 5 Select the phone number you want to use for outgoing calls. Then click on " Next " Now select the phone number under which the new telephone is to be reached (usually the same phone number as the outgoing number). Then click on "...
  • Page 6 How do I get into the web user interface of a Snom DECT base M-Series Since automatic provisioning is not supported by the Fritzbox, the Snom DECT base must be set up via your web user interface (WUI). To access the base, enter the IP address of your phone in your Internet browser (e.g.
  • Page 7 More information on how to add an extension to a Snom DECT base of the M series can be found here: DECT - 3.1 Add Extensions For direct configuration of a snom phone on any other router (without SIP registrar feature) on a telecom line they need a different configuration:...
  • Page 8 Setting up a Snom Phone on 3CX PBX Setting up a Snom C520 WiMi on a FritzBox Setting up a Snom DECT Base of the M-SC-Series on a FritzBox Setting up a Snom DECT Base of the M-Series on a FritzBox...
