3. Install the
container as shown in the picture (top
view)

Drain Hose Installation

Before using the device, make sure the drain hose is properly installed
1. Attach the washing machine drain hose to the tee connection and
install a circlip to seal the connection.
2. Attach the supplied drain hose to the tee connection and install a
circlip to seal the connection. You can install the drain hose in the
following 2 (two) ways:
3. If the drain hose is too long, it can be cut as needed.
tee connection on the
9
