Control Panel

Note: The control panel image is for reference only, actual product may have differences
1 Power
Press the Power button for 3 seconds to turn on and/or turn off the machine. If
there is no button operation in the on condition within 10 minutes, the machine
will automatically turn off.
2 Start/Pause
In standby condition, press this button to start or pause the program. When in
standby or suspend mode, the ":" mark on the display will light up. When the
program is running, the ":" sign will flash.
If you want to load the remaining laundry into the washing machine, while the
machine is running, press the Washer button and press and hold the Start/Pause
button for 3 seconds. The machine will detect the temperature and water level.
If it is at a safe temperature and level, the door can be opened and you can load
the laundry into the washing machine.
If you want to put the remaining laundry into the dryer, press the Dryer button
and press the Start/Pause button. The door can be opened and you can load
the laundry into the dryer.
3 Washer
In standby state, press this button to enter washing mode. The panel will display
programs and personalization for washing.
4 Dryer
In standby state, press this button to enter drying mode. The panel will display
programs and personalization for drying.
5 Smart Link
In standby condition, press the Washer button, then press the program button
that supports Smart Link, then press the Smart Link button.
6 Program
Program display is available in Washer and Dryer mode. When a program is
selected, the icon will flash and other program icons will light normally. A list of
programs can be seen in the next table.
