Do not place the appliance on top of a desk to prevent the appliance
from falling down
•
Press the four top corners of the
appliance, the appliance should not be
able to wobble. If the appliance wobbles,
readjust the feet
•
The maximum recommended surface
angle is no more than 2°.
Adjustable Feet Structure
Locking nut
Adjustable foot

Dryer Installation

WARNING!
Installation of dryer should be performed by 2 (two) or more people.
1. Lift the dryer and place it on top of the washer unit.
Make sure the four bottom corners of the dryer meet
the four top corners of the washing machine.
2. Tilt the dryer unit so that the back touches the wall as
shown in the picture and must be held by one person
to prevent the dryer from falling.
3. Take the cord from the bottom of the dryer and the
cord from the top of the washer. Connect the dryer and
washing machine cable connectors.
Default position
Locking nut and
feet are in fully
locked position
