Modena WW 1139 VSDG User Manual Book page 12

WARNING!
After installing the inlet hose, check for leakage. If there's a
leakage, repeat above steps until there is no leakage left.
Installing Inlet Hose to the Washing Machine
Connect the other end of inlet hose to the inlet valve located on the back
of the washing machine. Tighten the locking nut.
Inlet water valve
Inlet water hose
WARNING!
1. This washing machine is not designed for hot water source use.
The inlet water temperature should be less than 30°C
2. The inlet water pressure should be between 0.05-0.8 MPa
3. Do not use the water inlet hose from another unit or an old unit
Install the inlet hose to the adapter by sliding and
holding the part (c), insert the hose until you hear
a click sound.
12
Inlet water hose
