Purity Ultra Minimal Shower Mixer
Stainless Steel
PUR034
9 421027 596917
Congratulations on your purchase of this high quality product from Foreno Tapware.
Please read the following before installation and retain (along with your receipt) for future reference.

TECHNICAL SPECIFICATIONS

Suitable for Mains Pressure only
Minimum Pressure = 150kPa
Maximum operating Pressure = 500kPa
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.

CONFIGURATION

Mains Pressure systems Install as supplied.
Unequal Low systems
Equal Low systems

INSTALLATION

Installation must comply with Section 5.4 of AS/NZS 3500 Standard with regard to Isolating stop cock use. Shower
mixers must be water tested with the outlet open, to prevent damage to cartridge seals; due to back pressure.
All pipe work must be flushed prior to the installation of this mixer, accessible inline filters must be installed in the
pipework for both the hot and cold inlet supply to prevent particles from damaging the ceramic cartridge.
Any water seepage from the cartridge cavity opening can be stopped by re-tightening the large brass retaining nut.
Important: The maximum wall hole diameter is 55mm.
Connect the mixer body to internal pipe inlets and outlet.
Avoid restrictive piping, fittings or sharp angled bends when plumbing for this mixer.
It is the responsibility of the installer to ensure a water proof seal is achieved between the faceplate and the
wall surface.
Turn on water supply.
Check for leaks.
FORENO TAPWARE (NZ) LTD | Freephone: 0508 FORENO | info@foreno.co.nz | 5 Hewlett Street, Port Whangarei 0110 | FORENO.CO.NZ
This product is not suitable for this type of water pressure.
This product is not suitable for this type of water pressure.
