System System menu.
Beep
PowerOn
I/O Config Select the interface communicated with the computer.
I/O Ad-
vance
Config
Set the beeper status.
Off
On
Set the power-on state.
Reset
Last
Last+Off
USB
LAN
I/O Advance configuration. Based on the communication interface se-
lected by I/O Config, display configurable parameters of the communica-
tion interface in detail.
When the I/O Config selects the GPIB interface, the following
GPIB
information is displayed.
GPIB Address
When the I/O Config selects the USB interface, the following
USB
information is displayed.
USBTM-
C&USBVCP
When the I/O Config selects the LAN interface, the following
LAN
information is displayed.
IP
Config
Copyright © Itech Electronic Co., Ltd.
Turn the beeper off.
Turn the beeper on.
When the power source is powered on, the power
source will initialize some settings and output state.
When the power source is powered on, the power
source will remain the same settings and output state
as last time you turned off the power source.
When the power source is powered on, the power
source will remain the same settings as last time you
turned off the power source, but the output state is
OFF state.
USB communication interface.
USB communication interface.
Set the communication address within
the range from 1 to 30.
It is unnecessary to set the advancing
parameters for this interface.
Set the address of the instrument.
IP Mode Set IP mode.
Auto
Manu
Quick Reference
Auto: automatically configure
the address of the instrument.
Manual: manually configure
the address of the instrument
by entering values in the fol-
lowing five fields.
The following information only
appear when Manu is
selected.
