- Page 1 HADA Series NETWORKABLE AMPLIFIERS Digital Amplifiers USER MANUAL 50-0439-0100 HADA SERIES...
-
Page 2: Table Of Contents
TABLE OF CONTENTS PRECAUTIONS .......................... 4 1.1 Important Notice ......................... 4 1.2 Key Safety Directions ........................ 5 1.3 Cleaning Directions ........................5 WARRANTY & ENVIRONMENT .................... 6 PACKAGE CONTENTS ......................6 DESCRIPTION & FEATURES ....................7 4.1 Main Features ..........................7 PANEL FUNCTIONS ......................... - Page 3 8.2.1 HADA-4B150 ..........................35 8.2.2 HADA-4B250 ..........................36 8.2.3 HADA-4B400 ..........................37 8.2.4 HADA-4B500 ..........................38 8.2.5 HADA-4B750 ..........................39...
-
Page 4: Precautions
WARNING: Ecler products have a long lifetime of more than 10 years. This product must never be discarded as unsorted urban waste, but must be taken to the nearest electrical and electronic waste treatment centre. -
Page 5: Key Safety Directions
1.2 Key Safety Directions Read the following directions. 11. Only use attachments/accessories specified by the manufacturer. Keep the following directions. 12. Unplug the device during lightening Heed all warnings. sorts or when unused for long periods of Follow all directions. time. -
Page 6: Warranty & Environment
Recycling materials and using non-contaminant components are also top priorities in our green crusade. Ecler has deeply evaluated and analyzed the environmental impacts of all the processes involved in the production of this product, including packaging, and has alleviated, reduced and/or compensated for them. -
Page 7: Description & Features
4. DESCRIPTION & FEATURES HADA Series is a family of digital amplifiers, with different power levels: HADA-4B150 with 125W, HADA-4B250 with 250W, HADA-4B400 with 400W, HADA-4B500 with 500W and HADA-4B750 with 750W. All the models include 4 amplified channels that support Hi-Z and Low-Z loads down to 4 ohms. -
Page 8: Panel Functions
5. PANEL FUNCTIONS 5.1 Front Panel ON/Standby Button: the equipment is switched on by default just switching to ON the rear power switch. • When the ON LED of the front panel is lit in white, the device is operational. •... -
Page 9: Rear Panel
Mute indicator LED: lights up in white colour when the amplified output is muted. Prot. indicator LED: lights up in red colour when any protection of the power module is active (along with the mute LEDs of the channels that are failing), or when the standby mode is active (along with the ON LED). -
Page 10: Install & Connect
(micro, line…). This may cause the system to oscillate, damaging the amplifier and speakers. 6.1 Location, Assembly and Ventilation HADA series devices have a 19" rack format (2RU). It is very important not to enclose the amplifier or expose it to extreme temperatures as it generates heat. -
Page 11: Mains Connection
6.2 Mains Connection HADA operates on alternating voltages from 90 to 264V and 47 to 63Hz. This device is equipped with an oversized power supply capable of adapting without any type of adjustment to the mains voltage of any country in the world. On the rear panel, there is an on/off switch for the unit. -
Page 12: Analogue Input Connections
6.3 Analogue Input Connections HADA rear panel provides analogue, balanced, line level signal inputs. The selection of hardware inputs and their routing and mixing towards either amplifier channel is performed from its embedded web application. For further information, please refer to HADA DSP Manager chapter. -
Page 13: Amplified Output Connections
6.4 Amplified Output Connections The rear panel is fitted with two position screw terminal block for each amplified output. Always respect the relative polarity for outputs (+ and - on each output connector), wiring and speakers. 6.4.1 Out Configurations HADA DSP Manager software allows to configure the amplifier to operate in high impedance/bridge mode, or low impedance. -
Page 14: Remote Volume
6.5 Remote Volume HADA rear panel provides four remote control ports, labelled "REMOTE VOL 1-4", to which you can connect analogue devices such as the WPa series wall panels or common 10 Kohm linear potentiometers. These ports allow to control the volume of the output channels: each REMOTE VOL input is associated with its own corresponding output channel. -
Page 15: Ethernet Ports
6.7 Ethernet Ports The RJ-45-type ETHERNET connector on the rear panel, named NET, allows the equipment to be connected to an Ethernet network, or directly to a computer or other device with an Ethernet interface, point-to-point. This connection enables, within a local network, the following: •... -
Page 16: Start-Up & Operation
7. START-UP & OPERATION 7.1 Start-up When the rear panel Power switch is ON, the amplifier is powered, and it will automatically switch on. When the ON LED of the front panel is lit in white, the device is operational. To enter in standby mode, press and hold the ON button until all LEDs on the front panel blink once. -
Page 17: Hada Dsp Manager Configuration
7.2 HADA DSP Manager Configuration Once the physical connections have been made, the HADA units must be configured using the HADA DSP Manager software. The HADA network interface comes from the factory in DHCP client mode. This means that if a DHCP server is present in the network, it will automatically provide the IP address to the device. -
Page 18: Bridge Mode And Hi-Z Mode
7.3 Bridge Mode and Hi-Z Mode Bridge or HiZ mode, which allows 100V/70V line loudspeakers to be connected, must be set via the HADA DSP Manager software. Please configure the correct output mode via software before connecting the loudspeakers line: •... -
Page 19: Recovery Mode
In case that a firmware issue appears, or a firmware update fails, the HADA unit will automatically load an emergency firmware called “Recovery Mode”. This allows to connect with Ecler HADA DSP Manager and update the firmware again with the correct firmware of each HADA model. -
Page 20: Technical Data
8. TECHNICAL DATA 8.1 Technical Specifications 8.1.1 HADA-4B150 HADA-4B150 INPUTS Number of Inputs 4 analogue input channels IN1-4: 3-pin Euroblock, balanced, pitch 3,5 mm. Analogue input connection type Input configuration Digital matrix 4 in x 4 amp. out (Settings by HADA DSP Manager) AMPLIFIED OUTPUTS Number of amplified outputs Amplified output connection type... - Page 21 TECHNOLOGIES Amplification technology Class D Cooling Fan (Forced air, front to back airflow. Temperature controlled continuously variable speed) Maximum fan noise 46 dB (Maximum acoustical noise @1m) PROTECTIONS DC protection Yes (Protects loudspeaker and installation against DC and infrasonic signals at the outputs) HF protection Yes (Protects the loudspeakers against non-audible, strong, non-musical high frequency signals)
- Page 22 AUDIO CONVERTERS Sampling rate 96 kHz Resolution 24 bit Dynamic range 113 dB PROCESSING Digital processing 64 bit Latency 500uS (Analogue IN to analogue OUT) Inputs processing Delay, Parametric EQ, Limiter, Multiband compressor (Settings via HADA DSP Manager) Outputs processing Delay, Parametric EQ, Limiter, Multiband compressor (Settings via HADA DSP Manager) Others...
-
Page 23: Hada-4B250
8.1.2 HADA-4B250 HADA-4B250 INPUTS Number of Inputs 4 analogue input channels IN1-4: 3-pin Euroblock, balanced, pitch 3,5 mm. Analogue input connection type Input configuration Digital matrix 4 in x 4 amp. out (Settings by HADA DSP Manager) AMPLIFIED OUTPUTS Number of amplified outputs Amplified output connection type 2-pin Euroblock. - Page 24 PROTECTIONS DC protection Yes (Protects loudspeaker and installation against DC and infrasonic signals at the outputs) HF protection Yes (Protects the loudspeakers against non-audible, strong, non-musical high frequency signals) Short-circuit protection Yes (Protects the amplifier from overcurrent, short circuit or other stressful events for the output stages with output reduction or MUTE (automatic protection reset)) Thermal protection Yes (Output power reduction when output stages...
- Page 25 PROCESSING Digital processing 64 bit Latency 500uS (Analogue IN to analogue OUT) Inputs processing Delay, Parametric EQ, Limiter, Multiband compressor (Settings via HADA DSP Manager) Outputs processing Delay, Parametric EQ, Limiter, Multiband compressor (Settings via HADA DSP Manager) Others Preset management, 4x4 Matrix Mixer (Settings via HADA DSP Manager) PHYSICAL Operating temperature...
-
Page 26: Hada-4B400
8.1.3 HADA-4B400 HADA-4B400 INPUTS Number of Inputs 4 analogue input channels IN1-4: 3-pin Euroblock, balanced, pitch 3,5 mm. Analogue input connection type Input configuration Digital matrix 4 in x 4 amp. out (Settings by HADA DSP Manager) AMPLIFIED OUTPUTS Number of amplified outputs Amplified output connection type 2-pin Euroblock. - Page 27 PROTECTIONS DC protection Yes (Protects loudspeaker and installation against DC and infrasonic signals at the outputs) HF protection Yes (Protects the loudspeakers against non-audible, strong, non-musical high frequency signals) Short-circuit protection Yes (Protects the amplifier from overcurrent, short circuit or other stressful events for the output stages with output reduction or MUTE (automatic protection reset)) Thermal protection Yes (Output power reduction when output stages...
- Page 28 PROCESSING Digital processing 64 bit Latency 500uS (Analogue IN to analogue OUT) Inputs processing Delay, Parametric EQ, Limiter, Multiband compressor (Settings via HADA DSP Manager) Outputs processing Delay, Parametric EQ, Limiter, Multiband compressor (Settings via HADA DSP Manager) Others Preset management, 4x4 Matrix Mixer (Settings via HADA DSP Manager) PHYSICAL Operating temperature...
-
Page 29: Hada-4B500
8.1.4 HADA-4B500 HADA-4B500 INPUTS Number of Inputs 4 analogue input channels Analogue input connection type IN1-4: 3-pin Euroblock, balanced, pitch 3,5 mm. Input configuration Digital matrix 4 in x 4 amp. out (Settings by HADA DSP Manager) AMPLIFIED OUTPUTS Number of amplified outputs 4 Amplified output connection type 2-pin Euroblock. - Page 30 PROTECTIONS DC protection Yes (Protects loudspeaker and installation against DC and infrasonic signals at the outputs) HF protection Yes (Protects the loudspeakers against non-audible, strong, non-musical high frequency signals) Short-circuit protection Yes (Protects the amplifier from overcurrent, short circuit or other stressful events for the output stages with output reduction or MUTE (automatic protection reset)) Thermal protection Yes (Output power reduction when output stages...
- Page 31 PROCESSING Digital processing 64 bit Latency 500uS (Analogue IN to analogue OUT) Inputs processing Delay, Parametric EQ, Limiter, Multiband compressor (Settings via HADA DSP Manager) Outputs processing Delay, Parametric EQ, Limiter, Multiband compressor (Settings via HADA DSP Manager) Others Preset management, 4x4 Matrix Mixer (Settings via HADA DSP Manager) PHYSICAL Operating temperature...
-
Page 32: Hada-4B750
8.1.5 HADA-4B750 HADA-4B750 INPUTS Number of Inputs 4 analogue input channels IN1-4: 3-pin Euroblock, balanced, pitch 3,5 mm. Analogue input connection type Input configuration Digital matrix 4 in x 4 amp. out (Settings by HADA DSP Manager) AMPLIFIED OUTPUTS Number of amplified outputs Amplified output connection type 2-pin Euroblock. - Page 33 PROTECTIONS DC protection Yes (Protects loudspeaker and installation against DC and infrasonic signals at the outputs) HF protection Yes (Protects the loudspeakers against non-audible, strong, non-musical high frequency signals) Short-circuit protection Yes (Protects the amplifier from overcurrent, short circuit or other stressful events for the output stages with output reduction or MUTE (automatic protection reset)) Thermal protection Yes (Output power reduction when output stages...
- Page 34 PROCESSING Digital processing 64 bit Latency 500uS (Analogue IN to analogue OUT) Inputs processing Delay, Parametric EQ, Limiter, Multiband compressor (Settings via HADA DSP Manager) Outputs processing Delay, Parametric EQ, Limiter, Multiband compressor (Settings via HADA DSP Manager) Others Preset management, 4x4 Matrix Mixer (Settings via HADA DSP Manager) PHYSICAL Operating temperature...
-
Page 35: Mechanical Diagrams
8.2 Mechanical Diagrams 8.2.1 HADA-4B150 Ecler HADA-4B150 Mechanical Diag ram 482,6 www.ecler.com 61-1116-0100... -
Page 36: Hada-4B250
8.2.2 HADA-4B250 Ecler HADA-4B250 Mechanical Diagram 482,6 61-1117-0100 www.ecler.com... -
Page 37: Hada-4B400
8.2.3 HADA-4B400 Ecler HADA-4B400 Mechanical Diagram 482,6 61-1118-0100 www.ecler.com... -
Page 38: Hada-4B500
8.2.4 HADA-4B500 Ecler HADA- 4B500 Mechanical Diagram 482,6 61 -1119 -010 0 ww w .ecler.com... -
Page 39: Hada-4B750
8.2.5 HADA-4B750 Ecler HADA- 4B750 Mechanical Diagram 482,6 61-1120 -010 0 ww w .ecler.com... - Page 40 NEEC AUDIO BARCELONA S.L. reserves the right to make changes or improvements in the design or manufacturing that may affect these product specifications. For technical queries contact your supplier, distributor or complete the contact form on our website, Support / Technical requests. Motors, 166‐168 08038 Barcelona, Spain Tel. (+34) 932238403 information@ecler.com www.ecler.com...
