Installation Instructions - Kurba

Models KBX-X-X, KBX-XX-X and KBX-X-X-BL

Please read all instructions prior to installation and keep for future reference!

Kurba Horizontal

IMPORTANT SAFETY INSTRUCTIONS!

WHEN INSTALLING OR USING THIS TRACK SYSTEM, BASIC SAFETY

PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING:

A. READ ALL INSTRUCTIONS.

B. DO NOT INSTALL THIS TRACK IN DAMP OR WET LOCATIONS.

C. DO NOT INSTALL ANY PART OF THE TRACK SYSTEM LESS THAN 5 FEET ABOVE THE FLOOR.

D. DO NOT INSTALL ANY LUMINAIRE ASSEMBLY CLOSER THAN 6 INCHES FROM ANY CURTAIN, OR SIMILAR COMBUSTIBLE MATERIAL.

E. DISCONNECT ELECTRICAL POWER BEFORE ADDING TO OR CHANGING THE CONFIGURATION OF THE TRACK.

F. DO NOT ATTEMPT TO ENERGIZE ANYTHING OTHER THAN LIGHTING TRACK LUMINAIRES ON THE TRACK. TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT

ATTEMPT TO CONNECT POWER TOOLS, EXTENSION CORDS, APPLIANCES, AND THE LIKE TO THE TRACK.

*LUMINII RESERVES THE RIGHTS TO CHANGE SPECIFICATION & INSTRUCTION WITHOUT NOTICE

REV0.4

02062024

Kurba Vertical

7777 Merrimac Ave

Niles, IL 60714

T 224.333.6033

F 224.757.7557

info@luminii.com

www.luminii.com

Need help?

Do you have a question about the Kurba and is the answer not in the manual?

Page 1 F. DO NOT ATTEMPT TO ENERGIZE ANYTHING OTHER THAN LIGHTING TRACK LUMINAIRES ON THE TRACK. TO REDUCE THE RISK OF FIRE AND ELECTRIC SHOCK, DO NOT ATTEMPT TO CONNECT POWER TOOLS, EXTENSION CORDS, APPLIANCES, AND THE LIKE TO THE TRACK. *LUMINII RESERVES THE RIGHTS TO CHANGE SPECIFICATION & INSTRUCTION WITHOUT NOTICE...
Page 2 CAUTION: Reference to below before installing Kurba 2.5“ When unpacking Kurba, carefully pull it out of the packaging box. Do not pull the cable, otherwise it may disable the function of the connector Note: Incorrect unpacking may cause PCB fracture or damage on electronic and lead to water ingression.
Page 3 NOTE: More than one person is recommended for this installation. Once the location or pattern is determined for Kurba to be installed, start off by marking the area. Amount of brackets may vary dependant upon pattern. Reference diagrams below.
Page 4 C .4 mounting surface Fix the rest in sequence along with the marks. Adjust the serrate silicone tape and remove the extra lengths at both ends. *LUMINII RESERVES THE RIGHTS TO CHANGE SPECIFICATION & INSTRUCTION WITHOUT NOTICE...
Page 5 (minimum) 8”away (maximum) Curved run with mounting brackets Carefully push the Kurba onto the channel or mounting brackets, then press in completely to secure in place. Kurba mounting channel When light length longer than 6ft, make sure somebody helps to Make sure the angle between the light and profile is not bigger than 15°, otherwise...
