SECTION 6 PARTS LIST

[VR UNIT]

REF ORDER
NO. NO.
R801 7210003130 VARIABLE
C802 4030006860 S.CERAMIC
W801 8900011900 CABLE
W802 8900011910 CABLE
EP801 0910055991 PCB

[CONNECTOR UNIT]

REF ORDER
NO. NO.
J851 6910015030 CONNECTOR
EP851 0910055632 PCB
[LOGIC UNIT]
REF ORDER
NO. NO.
IC421 1110001810 S.IC
IC471 1110003800 S.IC
IC481 1130007300 S.IC
IC491 1110003800 S.IC
IC551 1110005350 S.IC
IC581 1110005770 S.IC
IC591 1130010390 S.IC
IC661 1140011150 S.IC
IC681 1130007300 S.IC
Q411 1530003090 S.TRANSISTOR 2SC4213-B (TE85R)
Q431 1520000450 S.TRANSISTOR 2SB1132 T100 Q
Q432 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q441 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q442 1560001130 S.FET
Q443 1560001130 S.FET
Q444 1590000430 S.TRANSISTOR DTC144EUA T106
Q461 1590002530 S.TRANSISTOR UN911H (TX)
Q462 1590001920 S.TRANSISTOR UN911F (TX)
Q501 1590000430 S.TRANSISTOR DTC144EUA T106
Q531 1590001770 S.TRANSISTOR XP1213 (TX)
Q532 1530002850 S.TRANSISTOR 2SC4116-BL (TE85R)
Q551 1520000450 S.TRANSISTOR 2SB1132 T100 Q
Q552 1590001190 S.TRANSISTOR XP6501-(TX) .AB
Q553 1590000430 S.TRANSISTOR DTC144EUA T106
Q561 1510000670 S.TRANSISTOR 2SA1588-GR (TE85R)
Q651 1590001770 S.TRANSISTOR XP1213 (TX)
D451 1730002360 S.ZENER
D452 1790000950 S.ZENER
D453 1790000950 S.ZENER
D454 1790000950 S.ZENER
D581 1790001250 S.DIODE
D601 1790000620 S.DIODE
X601 6050011550 S.XTAL
DESCRIPTION
TP76N97N-13F-10KA-2497
C1608 JB 1H 102K-T
OPC-1192
OPC-1193
B 5982A
DESCRIPTION
IMSA-9230B-1-09Z135-T
B 5893B
DESCRIPTION
TA7368F (TP1)
NJM2904V-TE1
TC4W66FU (TE12L)
NJM2904V-TE1
NJM2870F05-TE1
S-80942CNMC-G9C-T2
HN58X2416TI
µPD780316GC-511-9EB
TC4W66FU (TE12L)
CPH3403-TL
CPH3403-TL
MA8062-M (TX)
MA8056-M (TX)
MA8056-M (TX)
MA8056-M (TX)
MA2S111-(TX)
MA77 (TX)
CR-747 (9.8304 MHz)
[LOGIC UNIT]
REF ORDER
NO. NO.
L421 6200010230 S.COIL
R411 7030003560 S.RESISTOR
R412 7030003560 S.RESISTOR
R413 7030003620 S.RESISTOR
R414 7030003820 S.RESISTOR
R415 7030003820 S.RESISTOR
R421 7030003260 S.RESISTOR
R422 7030003200 S.RESISTOR
R431 7030003610 S.RESISTOR
R432 7030003800 S.RESISTOR
R433 7030003480 S.RESISTOR
R434 7030003480 S.RESISTOR
R435 7030003500 S.RESISTOR
R441 7030003760 S.RESISTOR
R442 7030003760 S.RESISTOR
R443 7030003680 S.RESISTOR
R451 7030003280 S.RESISTOR
R452 7030003440 S.RESISTOR
R453 7410000950 S.ARRAY
R454 7030003560 S.RESISTOR
R461 7030003620 S.RESISTOR
R462 7030003520 S.RESISTOR
R463 7030003480 S.RESISTOR
R464 7030003580 S.RESISTOR
R465 7030003690 S.RESISTOR
R466 7030003560 S.RESISTOR
R467 7030003400 S.RESISTOR
R468 7030003680 S.RESISTOR
R469 7030003730 S.RESISTOR
R470 7030003680 S.RESISTOR
R471 7030003640 S.RESISTOR
R472 7030003590 S.RESISTOR
R473 7030003520 S.RESISTOR
R474 7030003520 S.RESISTOR
R475 7030010290 S.RESISTOR
R476 7030004740 S.RESISTOR
R477 7030004730 S.RESISTOR
R478 7030003520 S.RESISTOR
R481 7030003680 S.RESISTOR
R482 7030003680 S.RESISTOR
R491 7030003580 S.RESISTOR
R492 7030003720 S.RESISTOR
R493 7030003770 S.RESISTOR
R494 7030003680 S.RESISTOR
R495 7030003520 S.RESISTOR
R496 7030003720 S.RESISTOR
R497 7030003710 S.RESISTOR
R498 7030003680 S.RESISTOR
R501 7030003680 S.RESISTOR
R502 7030003620 S.RESISTOR
R503 7030003690 S.RESISTOR
R504 7030003560 S.RESISTOR
R511 7030003610 S.RESISTOR
R512 7030003700 S.RESISTOR
R513 7030003590 S.RESISTOR
R521 7030003420 S.RESISTOR
R531 7030003600 S.RESISTOR
R532 7030003600 S.RESISTOR
R533 7030003650 S.RESISTOR
R534 7030003710 S.RESISTOR
R535 7030003560 S.RESISTOR
R536 7030003640 S.RESISTOR
R537 7030003640 S.RESISTOR
R538 7030003440 S.RESISTOR
R539 7030003640 S.RESISTOR
R540 7030003580 S.RESISTOR
R551 7030003560 S.RESISTOR
R552 7030003480 S.RESISTOR
R553 7030003600 S.RESISTOR
R561 7030003560 S.RESISTOR
R562 7030003520 S.RESISTOR
R571 7030005930 S.RESISTOR
R572 7030008090 S.RESISTOR
R581 7030003560 S.RESISTOR
6 - 1
DESCRIPTION
EXCCL3216U1
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 155 V (1.5 MΩ)
ERJ3GEYJ 155 V (1.5 MΩ)
ERJ3GEYJ 330 V (33 Ω)
ERJ3GEYJ 100 V (10 Ω)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 105 V (1 MΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 332 V (3.3 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 474 V (470 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 470 V (47 Ω)
ERJ3GEYJ 102 V (1 kΩ)
EXB-V8V 102JV
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 124 V (120 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 471 V (470 Ω)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 274 V (270 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYF 273 V (27 kΩ)
ERJ3GEYF 392 V (3.9 kΩ)
ERJ3GEYF 222 V (2.2 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 564 V (560 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYJ 224 V (220 kΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 104 V (100 kΩ)
ERJ3GEYJ 333 V (33 kΩ)
ERJ3GEYJ 124 V (120 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 273 V (27 kΩ)
ERJ3GEYJ 154 V (150 kΩ)
ERJ3GEYJ 183 V (18 kΩ)
ERJ3GEYJ 681 V (680 Ω)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 563 V (56 kΩ)
ERJ3GEYJ 184 V (180 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 102 V (1 kΩ)
ERJ3GEYJ 473 V (47 kΩ)
ERJ3GEYJ 153 V (15 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 222 V (2.2 kΩ)
ERJ3GEYJ 223 V (22 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
ERJ3GEYJ 472 V (4.7 kΩ)
ERJ3GEYF 334 V (330 kΩ)
ERJ3EKF 1503 V (150 kΩ)
ERJ3GEYJ 103 V (10 kΩ)
S.=Surface mount
