Icom IC-M88 Service Manual page 27

• BC-152 CHARGER PARTS LIST
ELECTRICAL PARTS
REF ORDER
DESCRIPTION
NO. NO.
IC1 1180000970 S.IC AN78L05M-(E1)
IC2 1190001180 S.IC MM1332BFBE
IC3 1110005960 S.IC S-80833CNMC-B8S-T2
IC4 1190001470 S.IC TB1009AF(EL)
IC5 1110002700 S.IC NJM2904M-TE1
Q1 1540000550 S.TRANSISTOR 2SD1664 T100Q
Q2 1510000500 S.TRANSISTOR 2SA1162-GR (TE85R)
Q3 1590002880 S.FET 2SJ417-TL
Q4 1520000450 S.TRANSISTOR 2SB1132 T100 Q
Q5 1590000700 S.TRANSISTOR DTC144EKA T146
Q6 1590000930 S.TRANSISTOR DTA144EKA T146
D1 1790000670 S.DIODE SB07-03C-TB
D2 1730002540 S.ZENER MA8130-L(TX)
D3 1750000150 S.DIODE DA204K T146
D4 1730002460 S.ZENER MA8330-M(TX)
D5 1750000550 S.DIODE 1SS355 TE-17
D6 1160000070 S.DIODE DAN202K T146
D7 1730002320 S.ZENER MA8051-M(TX)
R1 7030000380 S.RESISTOR MCR10EZHJ 1 kΩ(102)
S.RESISTOR MCR10EZHJ 10 Ω (100)
R2 7030000140
S.RESISTOR MCR10EZHJ 10 Ω (100)
R3 7030000140
R4 7030000450 S.RESISTOR MCR10EZHJ 3.9kΩ (392)
R5 7030000450 S.RESISTOR MCR10EZHJ 3.9kΩ (392)
R6 7030000500 S.RESISTOR MCR10EZHJ 10 kΩ (103)
R7 7030002920 S.RESISTOR MCR10EZHFX 39 kΩ (393)
R8 7030000580 S.RESISTOR MCR10EZHJ 47 kΩ (473)
R9 7030000420 S.RESISTOR MCR10EZHJ 2.2kΩ (222)
S.RESISTOR MCR10EZHJ 100 Ω (101)
R10 7030000260
R11 7030000500 S.RESISTOR MCR10EZHJ 10 kΩ (103)
R12 7030000530 S.RESISTOR MCR10EZHJ 18 kΩ (183)
R13 7030001780 S.RESISTOR MCR10EZHFX 18 kΩ (183)
R14 7030000500 S.RESISTOR MCR10EZHJ 10 kΩ (103)
R15 7030000500 S.RESISTOR MCR10EZHJ 10 kΩ (103)
R16 7030000540 S.RESISTOR MCR10EZHJ 22 kΩ (223)
R17 7030010150 S.RESISTOR MCR10EZHF 2943 (294kΩ )
R19 7030000530 S.RESISTOR MCR10EZHJ 18 kΩ (183)
S.RESISTOR MCR10EZHJ 220 Ω (221)
R20 7030000300
R21 7030000500 S.RESISTOR MCR10EZHJ 10 kΩ (103)
R22 7030000540 S.RESISTOR MCR10EZHJ 22 kΩ (223)
R23 7030000550 S.RESISTOR MCR10EZHJ 27 kΩ (273)
S.RESISTOR MCR10EZHJ 1 Ω (010)
R24 7030000020
S.RESISTOR MCR10EZHJ 1 Ω (010)
R25 7030000020
R27 7030000580 S.RESISTOR MCR10EZHJ 47 kΩ (473)
R28 7030000500 S.RESISTOR MCR10EZHJ 10 kΩ (103)
R29 7030000680 S.RESISTOR MCR10EZHJ 330 kΩ (334)
R30 7030000510 S.RESISTOR MCR10EZHJ 12 kΩ (123)
C1 4030004750 S.CERAMIC C2012 JB 1H 103K-T
C2 4510005340 ELECTROL 25 MV 47 HC
C3 4030008960 S.CERAMIC C2012 JB 1C 104K-T
C4 4030004720 S.CERAMIC C2012 JB 1H 102K-T
C5 4030004720 S.CERAMIC C2012 JB 1H 102K-T
C6 4510006160 ELECTROL 25 MV 10 HC
C7 4030008960 S.CERAMIC C2012 JB 1C 104K-T
C8 4030008960 S.CERAMIC C2012 JB 1C 104K-T
C9 4510006160 ELECTROL 25 MV 10 HC
C10 4030008960 S.CERAMIC C2012 JB 1C 104K-T
C11 4030008660 S.CERAMIC C2012 JB 1H 333K-T
C12 4030008960 S.CERAMIC C2012 JB 1C 104K-T
C13 4510006160 ELECTROL 25 MV 10 HC
C14 4030008960 S.CERAMIC C2012 JB 1C 104K-T
C15 4030008960 S.CERAMIC C2012 JB 1C 104K-T
J1 6510023070 CONNECTOR HEC2305-01-250
DS1 5040001390 LED TLG124A
REF ORDER
QTY.
DESCRIPTION
NO. NO.
1 W1 7030000010 S.JUMPER MCR10EZHJ JPW (000)
1 W2 7030000010 S.JUMPER MCR10EZHJ JPW (000)
1 W3 7030000010 S.JUMPER MCR10EZHJ JPW (000)
1 W4 7030000010 S.JUMPER MCR10EZHJ JPW (000)
1
EP1 910055642 PCB B 5894B
1
1
1
1
MECHANICAL PARTS
1
CHASSIS PARTS (C)
1
REF ORDER
DESCRIPTION
NO. NO.
1
1 MP1 8010019100 Case 2612
1 MP4 8110007810 Cover 2612
1 MP5 8810008660 Screw BT M3 x 8 NI-ZU
1 MP6 8930039620 LEG cushion (A)
1 MP7 8930056330 Summary sheet (Z) TC-100TK (7 x 7)
1
CHARGER PARTS (CH)
1
REF ORDER
1
DESCRIPTION
NO. NO.
1
MP1 8930051341 2338 TERMINAL-1
1
MP2 8930051341 2338 TERMINAL-1
1
MP3 8930051341 2338 TERMINAL-1
1
MP4 8930051341 2338 TERMINAL-1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1 MP1 (CH)
MP1 (C)
1
MP2 (CH)
1
MP3 (CH)
1
MP4 (CH)
1
1
1
1
1
MP7 (C)
1
1
1
MP4 (C) MP5 (CH)
1
1
1
1
1
1
1
1
1
MP5 (C)
MP6 (C)
MP6 (C)
1
(C): CHASSIS PARTS
1
(CH): CHARGER PARTS
ACCESSORY PARTS
REF ORDER
QTY.
NO. NO.
1 MP1 8810001470 Screw.5 x 30 SUS
1
1
1
1
QTY.
1
1
3
2
1
QTY.
1
1
1
1
• BC-152 VOLTAGE DIAGRAM
J1
HEC2305-01-250
13.7V
R10 IC1
100
AN78L05M
I
G
C7
0.1
R14
R16
10k 22k
0V
R15
10k
W3
W4
QTY.
DESCRIPTION
2
Q2
2SA1162 R4
3.9k
11.3V
DS1
TLG124A
R5
3.9k
Q1 R6
Q3
10k
D1 2SD1664
R2 2SJ417
SB07-03C
10
R1
1k D3
7.7V
C1 C6
C3 C4 DA204K
0.01 0.1 0.001 1
R3 C5
D2 10 0.001
C14 C2
MA8130
0.1
47
R7
39k
Q5
W2 W1
DTC144EKA
2.3V
R12
1 8 18k D6
SW1 VCC
DAN202K
2 7
O SW2 EXT
3 6
LV CEL
4 5
D5
GND CS
R11 R13
1SS355
IC2 18k
C8 10k
0V 0V
0.1
MM1332BFBE
C13 C15
1 0.1
5.0V
R19
Q6 18k
DTA144EKA
IC4
IC5
TB1009AF
NJM2904M
1 10
CHRGEOUT VDD
2 9 R28
1
SHORTDETECT TEST
3 8 R17 10k
BTDETECT PULSESELECT
294k 2
4 7
LEDOUT COUNTERSELECT
5 6 3
GND OSC
4
C11
0.033
C9 C10 R27
47k
1 0.1
CHARGER UNIT
7 - 3
Q4
2SB1132
7.1V 7.0V
MP1
R8
47k
D4
MA8330
R9
2.2k
MP2
B
IC3
S-80833CNMC
1 5
OUT CD
2
VDD
3 4
VSS NC
R20
220
MP3 T
D7
MA8051
R29 R22 R21
330k 22k 10k
8
7
6
MP4
5
2.6V
R23 R30 R24 R25
27k 12k 1 1
C12
0.1
