Installation Guide
Sight glass
LLG
1
3
Segment with 20 screws
4
© Danfoss A/S (MWA), 2015-02
2
Segment with 12 screws
DKRCI.PI.GG0.A2.ML / 520H8306
A
B
and
Nm
LLG
44
A
Note!
Bolts for flanges are not tightened from
factory. The bolts must be tightened
on site.
LB-feet
32
1
