  • Page 1 PCI-1407...
  • Page 2 IMAQ ™ ™ IMAQ PCI/PXI -1407 User Manual High-Quality Monochrome Image Acquisition Boards for PCI, PXI, and CompactPCI Bus IMAQ PCI/PXI-1407 User Manual August 2001 Edition Part Number 322156C-01...
  • Page 3 Sweden 08 587 895 00, Switzerland 056 200 51 51, Taiwan 02 2528 7227, United Kingdom 01635 523545 For further support information, see the Technical Support Resources appendix. To comment on the documentation, send e-mail to techpubs@ni.com. Copyright © 1998, 2001 National Instruments Corporation. All rights reserved.
  • Page 4 The reader should consult National Instruments if errors are suspected. In no event shall National Instruments be liable for any damages arising out of or related to this document or the information contained in it.
  • Page 5 Classification requirements are the same for the Federal Communications Commission (FCC) and the Canadian Department of Communications (DOC). Changes or modifications not expressly approved by National Instruments could void the user’s authority to operate the equipment under the FCC Rules.
  • Page 6 Canadian Department of Communications This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. Compliance to EU Directives Readers in the European Union (EU) must refer to the Manufacturer’s Declaration of Conformity (DoC) for information** pertaining to the CE Mark compliance scheme.
  • Page 7 Conventions The following conventions are used in this manual: ♦ The ♦ symbol indicates that the following text applies only to a specific product, a specific operating system, or a specific software version. This icon denotes a note, which alerts you to important information. This icon denotes a caution, which advises you of precautions to take to avoid injury, data loss, or a system crash.
  • Page 8: Table Of Contents

    Gain and Offset Circuitry ................3-2 8-Bit ADC and LUT..................3-2 CSYNC Mux ....................3-3 Genlock SYNC Generator................3-3 Pixel Aspect Ratio Circuitry................3-3 Acquisition and Region-of-Interest Control............3-3 FIFO Buffer .....................3-3 Scatter-Gather DMA Controllers ..............3-3 PCI Interface....................3-4 Trigger Control....................3-4 © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 9 Contents Video Acquisition......................3-4 Start Conditions....................3-4 Acquisition Window Control ................3-5 Programming Video Parameters ..............3-6 Acquisition Modes......................3-7 Chapter 4 Signal Connections BNC Connectors......................4-1 I/O Connector Signal Connection Descriptions..........4-2 Appendix A Specifications Appendix B Technical Support Resources Glossary Index Figures...
  • Page 10: About Your 1407 Device

    I/O line. If you require more advanced triggering or additional I/O lines (either digital or analog), you can use the PCI/PXI-1407 and NI-IMAQ with the National Instruments data acquisition (DAQ) product line.
  • Page 11: Using Pxi With Compactpci

    Using NI-IMAQ, the National Instruments image acquisition driver software, you can program your IMAQ device to acquire and save images. You can use NI-IMAQ with other National Instruments software for a complete image acquisition and analysis solution, as shown in Figure 1-1.
  • Page 12: Figure 1-1. The Relationship Between The Programming Environment, Ni-Imaq, And Your Hardware

    ROI Application Software Measurement Studio LabVIEW (LabWindows/CVI, Visual C++, Visual Basic) Driver Software NI-IMAQ NI-DAQ NI-Motion Hardware IMAQ ValueMotion/ FlexMotion Figure 1-1. The Relationship between the Programming Environment, NI-IMAQ, and Your Hardware © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 13: Ni-Imaq Driver Software

    Chapter 1 Introduction NI-IMAQ Driver Software The NI-IMAQ driver software is included with your IMAQ device. NI-IMAQ has an extensive library of functions that you can call from your application programming environment. These functions include routines for video configuration, image acquisition (continuous and single-shot), memory buffer allocation, trigger control, and board configuration, as shown in Figure 1-2.
  • Page 14: Imaq Vision

    Chapter 1 Introduction IMAQ Vision National Instruments’ IMAQ Vision is an image acquisition, processing, and analysis library of more than 200 functions for grayscale, color, and binary image display; image processing; pattern matching; shape matching; blob analysis; gauging; and measurement.
  • Page 15: Integration With Daq

    Figure 1-3. IMAQ Vision Builder and Application Development Tools Integration with DAQ Any platform that supports NI-IMAQ also supports NI-DAQ and a variety of National Instruments’ DAQ devices, allowing your IMAQ device and NI-IMAQ development to integrate with National Instruments’ DAQ products.
  • Page 16: Installation

    IMAQ BNC-1 shielded, 75 Ω BNC cable for VIDEO (included with your PCI-1407) ❑ Your Pentium-based PCI, PXI, or CompactPCI computer running Windows 2000/NT/Me/9x ❑ An analog video camera or other video source. See Appendix A, Specifications, for supported formats. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 17: Optional Equipment

    For more specific information about these products, refer to the National Instruments catalog or Web site, or call the office nearest you. How to Set up Your IMAQ System Use Figure 2-1 as a guide when installing the software and hardware, configuring the hardware, and using NI-IMAQ in your application programs.
  • Page 18: Figure 2-1. How To Set Up Your Imaq System

    NI-IMAQ functions. If you are using IMAQ Vision for LabWindows/CVI, read the documentation for IMAQ Vision for LabWindows/CVI. Figure 2-1. How to Set up Your IMAQ System © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 19: Safety Information

    If the device is damaged, turn it off and do not use it until service-trained personnel can check its safety. If necessary, return the device to National Instruments for repair. Keep away from live circuits. Do not remove equipment covers or shields unless you are trained to do so.
  • Page 20 (internal) mains-derived circuits Mains is defined as the electricity suppy system to which the equipment concerned is designed to be connected for either powering the equipment or for measurement purposes. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 21: Unpacking

    • Remove the device from the package and inspect it for loose components or any other signs of damage. Notify National Instruments if the device appears damaged in any way. Do not install a damaged device in your computer.
  • Page 22: Figure 2-2. Pci-1407 Parts Locator Diagram

    To protect both yourself and the computer from electrical hazards, the computer should remain off and unplugged until you finish installing the 1407 device. Follow the electrostatic discharge guidelines in the Safety Information section of this chapter. Remove the cover of your computer. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 23 Chapter 2 Installation Make sure there are no lit LEDs on your motherboard. If any are lit, wait until they go out before continuing your installation. Touch the metal part of the power supply case inside the computer to discharge any static electricity that might be on your clothes or body. Remove the top cover or access port to the PCI bus.
  • Page 24 Screw the front panel of the PXI-1407 to the front panel mounting rails of the PXI or CompactPCI chassis. Visually verify the installation. Plug in and turn on the PXI or CompactPCI chassis. Your PXI-1407 is now installed. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 25: Hardware Overview

    PCI bus. The device also includes a trigger for controlling the image acquisition. The block diagram in Figure 3-1 illustrates the key functional components of the PCI/PXI-1407. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 26: Video Buffer

    Chapter 3 Hardware Overview Trigger Control Trigger HSYNC and VSYNC Acquisition and CSYNC Genlock SYNC Region-of-Interest Generator PCLK Control CSYNC Pixel Aspect Ratio Correction PCI Interface Video 8-bit A/D Gain and FIFO Scatter-Gather Buffer and LUT Offset DMA Controllers Video Figure 3-1.
  • Page 27: Csync Mux

    FIFO memory buffers and the PCI bus. Each of these controllers These specifications apply only to revisions E and later of the PCI-1407, and revisions C and later of the PXI-1407. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 28: Pci Interface

    Chapter 3 Hardware Overview supports scatter-gather DMA, which allows the DMA controller to reconfigure on-the-fly. Thus, the PCI/PXI-1407 can perform continuous image transfers to either contiguous or fragmented memory buffers. PCI Interface The PCI/PXI-1407 implements the PCI interface with a National Instruments custom application-specific integrated circuit (ASIC), the PCI MITE.
  • Page 29: Acquisition Window Control

    Picture aspect ratio—The picture aspect ratio is the ratio of the active pixel region to the active line region. For standard video signals like RS-170 or CCIR, the full-size picture aspect ratio normally is 4/3 (1.33). © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 30: Programming Video Parameters

    Chapter 3 Hardware Overview • Pixel aspect ratio—The pixel aspect ratio is the ratio between the physical horizontal size and the vertical size of the region covered by the pixel. An acquired pixel should optimally be square, thus the optimal value is 1.0, but typically it falls between 0.95 and 1.05, depending on camera quality.
  • Page 31: Acquisition Modes

    PCI/PXI-1407 receives an incoming video signal (composite or luminance) and an external CSYNC signal from an external connector. The PCI/PXI-1407 takes the incoming CSYNC signal and generates HSYNC, VSYNC, and PCLK signals. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 32: Signal Connections

    PCI/PXI-1407 VIDEO, CSYNC, and TRIG inputs. Use BNC cables to connect a camera to these inputs. You can configure the BNC connector only for referenced single-ended (RSE) mode. VIDEO CSYNC TRIG Figure 4-1. PCI/PXI-1407 BNC I/O Connectors © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 33: I/O Connector Signal Connection Descriptions

    Chapter 4 Signal Connections I/O Connector Signal Connection Descriptions Table 4-1 describes each signal connection on the three BNC connectors. Table 4-1. I/O Connector Signals Signal Name Description VIDEO VIDEO± allows for an RSE connection to the video channel. The incoming video signal must be positive, as shown in Figure 3-2, Positive Video Line.
  • Page 34: Appendix A Specifications

    Quantity..........1 monochrome *Input impedance ........75 Ω (±1%), 1 Ω (±5%) Frequency response........ 15 MHz (–3 dB) typical *Input range ........... 700 mV (calibrated) or 60 mV to 1.26 V (variable gain) © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 35 Appendix A Specifications Accuracy *Absolute accuracy .......±2.5% of reading *Temperature drift ........< 500 ppm/°C A/D Conversion Gray levels ..........256 (8 bit) RMS noise ..........< 0.5 LSB rms Signal-to-noise ratio .......48 dB typical *Sampling rate ........11.7 to 31 MHz External Connections Trigger sense...........TTL Trigger level ...........Programmable (rising or falling) CSYNC sense .........TTL...
  • Page 36 Voltage ........... +5 V (1.34 A) +12 V (100 mA) –12 V (50 mA) Physical Dimensions PCI-1407 ......... 10.7 by 17.5 cm (4.2 by 6.9 in.) PXI-1407......... 16 by 10 cm (6.3 by 3.9 in.) © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 37 Appendix A Specifications Weight PCI-1407..........0.127 kg (0.28 lb.) PXI-1407 .........0.145 kg (0.32 lb.) Environment Operating temperature ......0 to 55 °C Storage temperature ........–20 to 70 °C Relative humidity ........10 to 90% RH, noncondensing Maximum altitude........2000 m Pollution degree ........2 Functional shock (PXI only)....MIL-T-28800 E Class 3 (per Section 4.5.5.4.1) Half-sine shock pulse, 11 ms duration, 30 g peak,...
  • Page 38 Meets the requirements of the following standards for safety for electrical equipment for measurement, control, and laboratory use: • EN 61010-1:1993/A2:1995, IEC 61010-1:1990/A2:1995 • UL 3101-1:1993, UL 3111-1:1994, UL 3121:1998 • CAN/CSA C22.2 no. 1010.1:1992/A2:1997 Installation category ....... I © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 39: Technical Support Resources

    Technical Support Resources Web Support National Instruments Web support is your first stop for help in solving installation, configuration, and application problems and questions. Online problem-solving and diagnostic resources include frequently asked questions, knowledge bases, product-specific troubleshooting wizards, manuals, drivers, software updates, and more. Web support is available through the Technical Support section of ni.com...
  • Page 40 Appendix B Technical Support Resources Worldwide Support National Instruments has offices located around the world to help address your support needs. You can access our branch office Web sites from the Worldwide Offices section of . Branch office Web sites provide ni.com...
  • Page 41: Glossary

    Positive of, or plus. – Negative of, or minus. Per. ± Plus or minus. Ω Ohm. Amperes. Analog-to-digital. Alternating current. acquisition window The image size specific to a video standard or camera resolution. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 42 Glossary active line region The region of lines actively being stored. Defined by a line start (relative to the vertical synchronization signal) and a line count. active pixel region The region of pixels actively being stored. Defined by a pixel start (relative to the horizontal synchronization signal) and a pixel count.
  • Page 43 D/A and/or DIO boards in the same computer. Decibel. The unit for expressing a logarithmic measure of the ratio of two signal levels: dB = 20log V1/V2, for signals in volts. Direct current. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 44 Glossary default setting A default parameter value recorded in the driver; in many cases, the default input of a control is a certain value (often 0) that means use the current default setting. display memory Dynamic link library. A software module in Microsoft Windows containing executable code and data that can be called or used by Windows applications or other DLLs;...
  • Page 45 Hertz. Frequency in units of 1/second. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 46 Glossary Input/output. The transfer of data to/from a computer system involving communications channels, operator interface devices, and/or data acquisition and control interfaces. Integrated circuit. IEEE Institute of Electrical and Electronics Engineers. Integral nonlinearity. A measure in LSB of the worst-case deviation from the ideal A/D or D/A transfer characteristic of the analog I/O circuitry.
  • Page 47 Continuous blocks of memory that can be accessed quickly by changing addresses on the local processor. Most significant bit. MTBF Mean time between failure. Multiplexer. A switching device with multiple inputs that selectively connects one of its inputs to its output. © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 48 Glossary NI-IMAQ Driver software for National Instruments IMAQ hardware. noninterlaced A video frame where all the lines are scanned sequentially, instead of divided into two frames as in an interlaced video frame. NVRAM Nonvolatile RAM. RAM that is not erased when a device loses power or is turned off.
  • Page 49 Also called a grounded measurement system. RTSI bus Real-Time System Integration Bus. The National Instruments timing bus that connects IMAQ and DAQ boards directly, by means of connectors on top of the boards, for precise synchronization of functions.
  • Page 50 Glossary sync Tells the display where to put a video picture. The horizontal sync indicates the picture’s left-to-right placement and the vertical sync indicates top-to-bottom placement. system RAM RAM installed on a personal computer and used by the operating system, as contrasted with onboard RAM.
  • Page 51: Index

    IMAQ system, 2-2 to 2-3 8-bit ADC and LUT, 3-2 CSYNC acquisition and region-of-interest acquisition window control, 3-5 control, 3-3 CSYNC mux, 3-3 acquisition modes, 3-7 external acquisition mode, 3-7 block diagram, 3-2 © National Instruments Corporation IMAQ PCI/PXI-1407 User Manual...
  • Page 52 DAQ, integrating with, 1-6 acquisition window control, 3-5 to 3-6 programming video parameters, 3-6 to 3-7 National Instruments web support, B-1 start conditions, 3-4 to 3-5 NI Developer Zone, B-1 video buffer, 3-2 NI-IMAQ driver software, 1-4...
  • Page 53 PXI-1407 device. See also PCI/PXI-1407 standard acquisition mode, 3-7 devices. start conditions, video acquisition, 3-4 to 3-5 using with CompactPCI, 1-2 system integration, by National Instruments, system requirements, 2-1 to 2-2 region of interest control circuitry, 3-3 programming video parameters,...
  • Page 54 Index VSYNC acquisition window control, 3-5 Web support from National Instruments, B-1 genlock synchronization generator, 3-3 worldwide technical support, B-2 IMAQ PCI/PXI-1407 User Manual ni.com...
