Summary of Contents for National Instruments PCIe-1427

  • Page 1 PCIe-1427...

  • Page 2: What You Need To Get Started

    Refer to the NI EVS-1463 Series User Manual for device and I/O specifications, mounting requirements, and answers to common questions about network, firewall, hardware, software, and power issues. To access the NI EVS-1463 Series User Manual, select Start»All Programs»National Instruments» Vision»Documentation»NI-IMAQ.

  • Page 3: Safety Information

    Misuse of the hardware can result in a hazard. You can compromise the safety protection if the hardware is damaged in any way. If the hardware is damaged, return it to National Instruments for repair. Clean the hardware with a soft, nonmetallic brush. Make sure that the hardware is completely dry and free from contaminants before returning it to service.

  • Page 4: Electromagnetic Compatibility Information

    The Declaration of Conformity (DoC) contains important EMC compliance information and instructions for the user or installer. To obtain the DoC for this product, visit , search by model number or product line, ni.com/certification and click the appropriate link in the Certification column. © National Instruments Corporation Getting Started with the NI EVS-1463...

  • Page 5: Thermal Considerations And Mounting

    Unpacking and Verifying Components Remove the NI EVS-1463 from the package and inspect the device for any sign of damage. Notify National Instruments if the device appears damaged in any way. Do not use a damaged device. Installing Hardware Ensure that the AC input to the external power supply is disconnected before plugging in or unplugging any connector.
  • Page 6 100 m. If you are using a 1,000 Mbps Ethernet, use a CAT 5e or CAT 6 shielded twisted-pair Ethernet cable. Use a shielded twisted pair Ethernet cable for maximum signal integrity. Connect devices to other connectors as required by your system configuration. © National Instruments Corporation Getting Started with the NI EVS-1463...

  • Page 7: Connecting A Camera

    Complete the following steps to use Measurement and Automation Explorer (MAX) to associate a camera file with your Camera Link camera: Select Start»All Programs»National Instruments»Measurement & Automation to launch MAX. Expand the Devices and Interfaces branch of the configuration tree.

  • Page 8: Specifications

    Complete the following step for your camera type to select the camera: • Base Configuration Camera Link Compatible Cameras—Expand the NI-IMAQ Devices branch, then expand the NI PCIe-1427 branch and select Channel 0. • GigE Vision or DirectShow-Compatible USB Cameras—Expand the NI-IMAQdx Devices branch and select a camera.

  • Page 9: Electromagnetic Compatibility

    Operating Environment Ambient temperature range ........0 °C to 45 °C (IEC 60068-2-1 and IEC 60068-2-2) Relative humidity range (IEC 60068-2-56) ...10% to 90% noncondensing Caution Clean the NI EVS-1463 with a soft nonmetallic brush. Make sure that the system is completely dry and free from contaminants before powering-on the controller again.

  • Page 10: Online Product Certification

    Certification column. Environmental Management National Instruments is committed to designing and manufacturing products in an environmentally responsible manner. NI recognizes that eliminating certain hazardous substances from our products is beneficial not only to the environment but also to NI customers.

  • Page 11: Where To Go From Here

    NI Vision Development Module by selecting Start»All Programs»National Instruments»Vision»Documentation»NI Vision. Documentation for the NI-IMAQ driver software is available by selecting Start»All Programs» National Instruments»Vision»Documentation»NI-IMAQ. Documentation for the NI-IMAQdx driver software is available by selecting Start»All Programs» National Instruments»Vision»Documentation»NI-IMAQdx.

  • Page 12: Where To Go For Support

    National Instruments corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504. National Instruments also has offices located around the world to help address your support needs. For telephone support in the United States, create your service request at ni.com/...
  • Page 13 National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation. Refer to the Terms of Use section on ni.com/legal for more information about National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your...
