Programming Your Controller - Innotech Micro2000 M2K06 Manual

When Parameter 9 is set to "On", the Time button allows you
to enable or disable the Time Clock. Any Schedules that have
been programmed will not function unless the Time LED is
On. When the Time button is pressed, the current time is
displayed for 5 seconds and then reverts back to the current
temperature.
Timer Mode
When Parameter 9 is set to "Off", the Time button is used
as an adjustable On or Off timer. When pressed, the display
will show the time in hours before the controller will change
state.
0.1 hours = 6 minutes.
If the unit is off, the controller will display the time till the
unit will turn on. If the unit is on, it will display the time it
will turn off.
The time displayed may be adjusted by pressing the
and buttons until you have adjusted to the time
required. If no buttons are pressed for 5 seconds, the display
will revert back to the current temperature. When the timer
has been set, the Time LED will be lit.
In Timer Mode, the Automatic Day / Night Change Over
functionality is not available.
5. The On / Off button is used to change the current
state of the controller. It can be used to override
either the Time Clock or Timer depending on which
mode is selected.
If the controller has been turned on by the Time Clock
Schedule, the is used to force the controller off till
the next scheduled "On" time. Similarly, if the controller
is Off, the can be used to force the controller on
until the next scheduled "Off" time.
6. The Up and Down buttons can be used to change
the current Setpoint.
Programming Schedules / Clock
The function of the buttons while in programming mode is
shown below.
Enter Back
Delete Copy
1. To enter the CLOCK / SCHEDULE programming mode,
press and hold the
screen becomes blank, stop holding down the button.
2. When you have entered the programming mode, "CLO"
will be displayed.
Use the and buttons to select a programming
mode:
Programming Modes
"CLO" Clock
"SCH" Schedules
"_d_n" Auto Day / Night Zone Change
To Select press the
To exit out of Schedules / Clock programming mode at any
time, press and hold the
3. If "CLO" was selected, the Current Time will be displayed.
Use the and buttons to adjust the current time
and press . The day is then displayed, use the
and buttons to select the required day. Day 1-7 =
Monday-Sunday. Press the
button to go back to programming mode selection.
Button for 5 seconds. When the
button.
Button for 5 sec then release.
button to select or
© MASS ELECTRONICS Pty Ltd 2008
4. If "SCH" was selected in step 2, you can now set / edit the
schedules. The display will initially show "Day1". Use the
arrows to select which Day you wish to view. Press the
button to select or
5. After you have selected the day, the display will initially show
"SCH1". Use the and
you wish to view. Press the
button to go back to Step 2.
6. After selection, you can now set the On and Off times for selected
Day and Schedule. Use the
Press the button to accept or the
back.
7. A Schedule can be deleted by pressing the
viewing the "On" time for the particular schedule you wish to
delete.
8. A copy function is available to copy a previous days schedule (Sch1
or Sch2). This can be done by pressing the
viewing the "On" time for the Schedule you wish to set.
9. If "_d_n" was selected in Step 2, you can program the Auto Zone
Change Over setting. The Display will initially show "A_00". Use
the and arrows to cycle through the three settings. Press
the button to select and edit the setting.
0 Enable / Disable Automatic Day / Night Change
1 Time to change from Day to Night
2 Time to change from Night to Day
These settings are used to automatically change the zone over at
the time programmed. If the Automatic Change Over is enabled,
then regardless of the Day and whether the controller is running or
not, the zone will be changed from Day to Night and Night to Day at
the programmed times.
The Auto Zone Change Over can only be used when the controller is
in Time Clock mode, set in Parameter 9.

Programming Your Controller

To enter into the programming mode, press and hold the
and the arrow for 5 seconds. When the screen becomes blank,
release the buttons.
• When you have entered the programming mode, "P 00" will be
displayed (P=Parameter, 00=Parameter 0).
• In the programming mode, the
Parameter is to be edited. (From Parameter 00 to 16).
• When you have selected the correct Parameter, press the
button. The value of that Parameter may then be altered by pressing
the or buttons. When you have adjusted the Parameter to
the desired setting, press the
• After confirming the changes (above), you will be back at the
Parameter selection stage once again. Select and change parameters
until have adjusted all Parameters you require.
• To EXIT the programming mode and SAVE your new settings, press
and hold the button for 5 seconds. When the screen becomes
blank, release the button.
Important Notes For Programming
• If you do not save your alterations, by holding the
5 seconds, the controller will revert to the last saved settings.
• If you are in the process of adjusting a Parameter (Using the
and buttons), and do not press any buttons for 30 seconds, the
controller will revert back to the Parameter selection screen. (Eg. P
00)
• If the Parameter selection screen (Eg. P 00) is left unaltered for 60
seconds, the controller will revert to the last saved setting, and exit
the programming mode.
DS 9.06 - M2K06 - Micro2000 Controller
August 2013
button to go back.
buttons to select which schedule
button to select or
and buttons to set the time.
button to go
button when
button while
button
and buttons select which
button to confirm the changes.
button for
Page 3
