5. The Up and Down buttons can be used to change
the current Setpoint.
After Hours Run Time
To view the accumulative After Hours Run Time, press and hold
the and buttons for 5 seconds. The displayed
value is the total after hours run time up to the previous hour. A
total of 9999 hours may be accumulated.
To reset the After Hours Run Timer, simply press and hold the
and buttons until the display reverts to 00.
To exit the After Hours Mode, press and hold the
button for 5 seconds again. The display will revert back to the
default display.
Start Up Default Settings
The Micro2000 can be set to start in certain modes of operation.
To set the start up defaults, adjust the controller to the desired
settings and then press and hold the
5 seconds. When the screen becomes blank, release the buttons
and the new Start Up Defaults will be saved.
Programming Schedules / Clock
The function of the buttons while in programming mode is
shown below.
Enter Back
Delete Copy
1. To enter the CLOCK / SCHEDULE programming mode,
press and hold the
screen becomes blank, stop holding down the button.
2. When you have entered the programming mode, "CLO"
will be displayed.
Use the and buttons to select either:
"CLO" Clock "SCH"
To Select press the
To exit out of Schedules / Clock programming mode at any
time, press and hold the
3. If "CLO" was selected, the Current Time will be displayed.
Use the and buttons to adjust. The
button can be used to toggle between the Time and Day.
Press the button to select or
back to mode selection.
4. If "SCH" was selected in step 2, you can now set / edit the
weekly schedules. The display will initially show "Day1".
Use the and arrows to select which Day you wish
to view. Press the
button to go back.
5. After you have selected the day, the display will initially
show "SCH1". Use the
which schedule you wish to view. Press the
to select or button to go back to Step 2.
6. After selection, you can now set the On and Off times for
that Day and Schedule. Use the
the time. Press the
button to go back.
7. A Schedule can be deleted by pressing the
when viewing the "On" time for the particular schedule you
wish to delete.
8. A copy function is available to copy a previous days
schedule (Sch1 or Sch2). This can be done by pressing
the button while viewing the "On" time for the
Schedule you wish to set.
and buttons for
Button for 5 seconds. When the
Weekly Schedules
button.
Button for 5 sec then release.
button to go
button to select or
and buttons to select
button
and buttons to set
button to accept or the
button
© MASS ELECTRONICS Pty Ltd 2008
All Time Clock functions can be disabled by setting Parameter 13
(Time Clock Enable) to "Off". In this mode the clock will not run and
access to the Schedule / Clock Menu is blocked.

Programming Your Controller

To enter into the programming mode, press and hold the
and the arrow for 5 seconds. When the screen becomes blank,
release the buttons.
• When you have entered the programming mode, "P 00" will be
displayed (P=Parameter, 00=Parameter 0).
• In the programming mode, the
Parameter is to be edited. (From Parameter 00 to 17).
• When you have selected the correct Parameter, press the
button. The value of that Parameter may then be altered by pressing
the or buttons. When you have adjusted the Parameter to
the desired setting, press the
• After confirming the changes (above), you will be back at the
Parameter selection stage once again. Select and change parameters
until have adjusted all Parameters you require.
• To EXIT the programming mode and SAVE your new settings, press
and hold the button for 5 seconds. When the screen becomes
blank, release the button.
Important Notes For Programming
• If you do not save your alterations, by holding the
5 seconds, the controller will revert to the last saved settings.
• If you are in the process of adjusting a Parameter (Using the
and buttons), and do not press any buttons for 30 seconds, the
controller will revert back to the Parameter selection screen. (Eg. P
00)
• If the Parameter selection screen (Eg. P 00) is left unaltered for 60
seconds, the controller will revert to the last saved setting, and exit
the programming mode.
Page 3
DS 9.02 - M2K02 - Micro2000 Controller
August 2013
button
and buttons select which
button to confirm the changes.
button for
