DS 9.06 - M2K06 - Micro2000 Controller
August 2013
Parameters
Parameter 0: Minimum Setpoint
The display will show the Minimum Setpoint to which the controller
can be set.
• The range of Minimum Setpoint is 0 to 50°C
• The factory default setting is 15°C
Parameter 1: Maximum Setpoint
The display will show the Maximum Setpoint to which the controller
can be set.
• The range of Maximum Setpoint is 0 to 50°C
• The factory default setting is 30°C
Parameter 2: Dead Band
The display will show the Dead Band setting.
• The range of the Dead Band is 0 to 9.9°C
• The factory default setting is 0.5°C
Parameter 3: Proportional Band
The display will show the Proportional Band Setting. A Proportional
Band setting of 2°C will result in a differential of 2°C for heating and
2°C for cooling.
• The range of Proportional Band is 0.5 to 9.9°C
• The factory default setting is 1.0°C
Parameter 4: Compressor Minimum Off Time
The display will show the Compressor Minimum Off Time.
This is the period the compressor must remain off before it can
restart.
• The range of the Off Time is 0 to 99 minutes
• The factory default setting is 4 minutes
Parameter 5: Fan Run On Time
The display will show the Fan Run On Time. This is the period the fan
will run for if it is operating in heating and the controller is turned off.
This is to remove any residual heat where electric heating is used.
• The range of the Run On Time is 0 to 99 seconds
• The factory default setting is 30 seconds
Parameter 6: EDH / REV
The display will show either EDH or REV to select which mode the
controller will operate.
• Electric Heat mode (EDH): the heat and cool relays operate
independently of each other.
• Reverse Cycle mode (REV): the cool relay controls the compressor
in both cooling and heating operations. The heat relay operates
the reversing valve.
• The factory default setting is EDH.
Parameter 7: HEA / COOL
The Display will show either HEA or COOL to select if the reversing
valve is energised for cooling or energised for heating.
• COOL: the heat relay will close during cooling
• HEA: the heat relay will close during heating
• The factory default setting is HEA
This parameter is only effective if Parameter 6 is set for Reverse
Cycle Operation.
Parameter 8: Fan Cycle
The Display will show either On or Off to select continuous fan
operation or fan cycles with heating.
• On: Fan cycles with heating
• Off: Fan runs continuously
• The factory default setting is Off
Parameter 9: Time Clock Function
The display will show either On or Off. This is used to enable or
disable the Time Clock function.
• On: Time Clock function Enabled
• Off: Time Clock Disabled - Timer Function used
• The factory default setting is Off
See "Time" button functionality for more information.
Parameter 10: Setpoint Display Only
The display will show either On or Off.
• On: The setpoint is displayed
• Off: The current temperature is displayed
• The factory default setting is Off
Parameter 11: Enable Both Zones
The display will show either On or Off. This is used to enable the
option of having both zones on at once.
• On: Enable both zones
• Off: Disable both zones
• The factory default setting is On
Parameter 12: Number of Sensors
The display will show the number of sensors used.
• One or two sensors can be selected
• The factory default setting is 1
Parameter 13: Number of Setpoints
The display will show the number of Setpoints used.
• 1 Setpoint used for both zones
• 2 Setpoints - each zone has its own setpoint
• The factory default setting is 1
Parameter 14: Sensor 1 Calibration
The display will show the actual temperature of sensor 1. To
offset the sensor temperature, adjust using the up and down
buttons.
• The range of offset is ± 10°C
• The factory default setting is 0.0°C
Parameter 15: Sensor 2 Calibration
The display will show the actual temperature of sensor 2. To
offset the sensor temperature, adjust using the up and down
buttons.
• The range of offset is ± 10°C
• The factory default setting is 0.0°C
Parameter 16: Standby Dead Band
The display will show the Standby Dead Band Setting.
• The range of the Standby Dead Band is OFF to 99.0°C
• If any value other than "Off" is selected and the controller
is in an "Off" state, it will not switch off. The controller will
instead go into a Standby mode. In this state the controller still
maintains the temperature of the selected zone, however it
will widen the control Dead Band by the selected amount. The
fan will also cycle on and off with the heating and cooling and
stay in low speed when in Standby.
• The factory default setting is OFF
