I N S T A L L A T I O N
CLAMP MOUNTING
When mounting the fixture to a truss or any other suspended structure, be sure to secure an appro-
priately rated clamp to the hole on the top of the mounting bracket. Insert a bolt of appropriate size
through the bottom of the mounting clamp and the hole on the mounting bracket, and secure them
together with a matching nut. Additionally, a safety cable of the appropriate weight rating should be
secured through one of the holes in the side of the mounting bracket.
MOUNTING
CLAMP
CLAMP BOLT
AND NUT
SAFETY
CABLE
ATTACHED
TO BRACKET
SAFETY CABLE:
ALWAYS ATTACH A SAFETY CABLE WHENEVER INSTALLING THIS FIXTURE
IN A SUSPENDED ENVIRONMENT TO ENSURE THAT THE FIXTURE WILL NOT
FALL IF THE CLAMP FAILS.
