EVB Interfaces

3.1. EVB Top View

EVB top view is shown in the figure below.
D514 (POWER and VCC indication LEDs)
D520 (TXD and 1PPS indication LEDs)
Test point 1
Test point 30
J402 (Test points)
EVB version
Test point 16
Test point 15
LC76G_Series_EVB_User_Guide
S201 (Power switch)
S503 (RESET button)
Figure 3: EVB Top View
J509 (USB to UART)
U512 (1PPS connector)
GNSS Module Series
U103 (LC76G GNSS module)
J103 (Antenna connector)
