ATTENTION!
• Make sure the drain hose is not crushed or damaged by a heavy
object falling on it. Otherwise, water drainage may be
obstructed and there is a risk of leakage.
• If the drain hose is installed by a technician, do not move the
position of the drain hose.
• Do not remove the circlip on the drain hose.
• If the drain hose is too long, do not force the hose into the drain
hose. You can cut the excess length according to the picture
above. If your drain hose is not long enough, contact after-sales
service.

Inlet Hose Installation

Faucet Types
Types of faucet that can and can't be used are as follows:
•
Type A: This faucet is suitable for washing machine
•
Type B: This faucet is suitable, however the front end should have
minimum length 10 mm. The front end should be flat and smooth,
otherwise it will cause leakage.
•
Type C: This faucet is not suitable and may cause leakage
Type A Type B
Min. 10 mm
8
Type C
Prone to
leakage
