Xerox WorkCentre 4150 Quick Reference

SERVICES:
JOB STATUS:
MACHINE STATUS:
Features* are accessible by touching All Services.
LOAD PAPER
LOAD PAPER
• Open the required
paper tray.
• Load the paper, do
not load above the
maximum fill line.
• Adjust the guides to
touch the edge of
the paper.
• Close the paper
tray, except the
Bypass Tray.
• Confirm the paper
size/type settings
on the user
interface.
For more information... 1. Press the Help button on the control panel, 2. refer to the Getting Started Guide, 3. refer
to the User Guide on the User Documentation CD, or 4. visit our website on...
Copyright © 2006 Xerox Corporation. All Rights Reserved
Displays the Services screen to enable selection of job features
Displays the job queue information
Displays machine information
FAX
QUICK FAX
• Load the original
face up in the
document handler.
• Select FAX from the
All Services screen.
• Enter the recipient
fax number using
the keypad or select
the number from the
ADDRESS BOOK.
• Touch the screen
buttons to make
feature selections.
• Press START.
WorkCentre 4150
TOUCH SCREEN - Displays all the available
features and general machine information
CLEAR ALL - Resets job programming to the
default settings
PAUSE - Interrupts current printing job
START - Starts the job
*Some features may not be available on your model.
E-MAIL
QUICK E-MAIL
• Load the original
face up in the
document handler.
• Select E-MAIL from
the All Services
screen.
• Input the E-mail
address or make a
selection from the
ADDRESS BOOK.
• Touch the screen
buttons to make
feature selections.
• Press START.
www.xerox.com/support
COPY
QUICK COPY
• Load the original
face up in the
document handler.
• Select COPY from
the All Services
screen.
• Touch the screen
buttons to make
feature selections.
• Press START.
