The contents of this envelope are the property of the owner.
Be sure to leave with the owner when installation is complete.
CAB INSTALLATION
BEFORE YOU START
HELPFUL REMINDERS:
Read and understand all instructions before beginning.
APPROXIMATE INSTALLATION TIME: 90 MINUTES (not including accessories)
Page 2
Safety Information
Page 3-4
Features and Accessories
Page 5-6
Tractor Preparation (mount and wiring install)
Page 7
Cab Installation
Page 8
Operation
Page 9
Cab Removal, Care and Maintenance
Page 10-14 Service Parts
KUBOTA F-SERIES CAB
p/n: F5206
P. 1 of 14
Rev. G (12/26/2023)
Manual p/n: 77700-05445
(p/n: F5206P1)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the F Series and is the answer not in the manual?

Questions and answers

Related Manuals for Kubota F Series

Summary of Contents for Kubota F Series

  • Page 1 P. 1 of 14 KUBOTA F-SERIES CAB p/n: F5206 The contents of this envelope are the property of the owner. Be sure to leave with the owner when installation is complete. CAB INSTALLATION BEFORE YOU START HELPFUL REMINDERS: Read and understand all instructions before beginning.

  • Page 2: Safety Information: ! Warning

    P. 2 of 14 SAFETY INFORMATION: WARNING: Cabs, blades, and general accessories add additional weight to the base vehicle. Deduct the accessory’s total weight from the vehicle’s rated capacity including driver and passenger. Never operate the vehicle outside of its rated weight capacity. WARNING: Exposure to Carbon Monoxide can cause illness, serious injury or death.
  • Page 3 P. 3 of 14 KEY FEATURES OF THE F5206 CAB: • Two (2) 8-LED Front Work Lights included • Heavy-Duty Pantograph Wiper system included • Large outer grab handles also perform as brush guards • Pre-Assembled Cab: The main cab ships fully assembled with a mount and hardware kit.

  • Page 4: Available Accessories

    P. 4 of 14 AVAILABLE ACCESSORIES: F5311 - Heater Kit with Quick-Connect Fittings F5312 - Rear LED Work Light Kit F5313 - Roof Mounted LED Strobe Light Kit F5314 - Interior Rearview Mirror...
  • Page 5 P. 5 of 14 TRACTOR PREPARATION: MOUNT KIT INSTALL TOOLS REQUIRED: • 13/16” SAE wrench or socket • Two (2) each, 12mm and 14mm Metric wrenches or sockets Lift the engine bonnet to the upward position and move the seat into its forward position.
  • Page 6 P. 6 of 14 2. TRACTOR PREPARATION: WIRING Wire tie relay and fuse holder to frame here TOOLS REQUIRED: • Wire Cutters (for wire ties) • 10mm Wrench or Socket Remove the nuts from the tractor battery terminals and attach the ring terminals from the relay harness onto the battery.

  • Page 7: Cab Installation

    P. 7 of 14 3. CAB INSTALLATION TOOLS REQUIRED: • Two (2) 3/4” and one (1) 1/2” SAE wrenches or sockets Lifting Rings • Two (2) 14mm and one (1) 12mm Metric wrenches or sockets QTY: HARDWARE 5/16-18 x 1” Flanged Head Bolts 1/2-13 x 1”...

  • Page 8: Operation

    P. 8 of 14 4. OPERATION 4.1 Buttons and Switches Standard switches for Windshield Wiper, Circulation Fans, and Front Work Lights are located above the windshield, to the left side of the cab (see fig. 4.1). NOTE: Do not use the Tractor front light with the cab installed. This light will cause glare on the inside of the cab windshield.

  • Page 9: Cab Removal

    P. 9 of 14 5. CAB REMOVAL 6. CARE AND MAINTENANCE • NOTE: This manual includes instructions only relevant to the This cab is designed to allow removal of the cab Cab. Refer to the owner’s manual included with the assembly per seasonal or other requirements.
  • Page 10 P. 10 of 14 F5206 F-SERIES CAB SERVICE PARTS - HARDWARE BOX REF. NO. KUBOTA P/N CODE NO. QTY. DESCRIPTION 77700-05429 KF2-11 REAR CENTER MOUNT 77700-05430 KF2-12L REAR LOWER MOUNT, LEFT 77700-05431 KF2-12R REAR LOWER MOUNT, RIGHT 77700-05432 KF2-13 REAR UPPER MOUNT CLAMP...
  • Page 11 P. 11 of 14 F5206 F-SERIES CAB SERVICE PARTS - SIDE FRAMES AND REAR PANEL REF. NO. KUBOTA P/N CODE NO. QTY. DESCRIPTION 77700-05426 KF2-09L SIDE FRAME WITH RUBBER ONLY, LEFT 77700-05427 KF2-09R SIDE PRAME WITH RUBBER ONLY, RIGHT 77700-05428...
  • Page 12 P. 12 of 14 F5206 F-SERIES CAB SERVICE PARTS - WINDSHIELD SUPPORT AND CONSOLE REF. NO. KUBOTA P/N CODE NO. QTY. DESCRIPTION 77700-05419 KF2-03 WINDSHIELD SUPPORT W/ CONSOLE 77700-05451 9PWA4A1-A WIPER MOTOR ASSEMBLY 77700-05258 FP-01 GANGED FUSE BLOCK, 6 POSITION, ATC STYLE...
  • Page 13 P. 13 of 14 F5206 F-SERIES CAB SERVICE PARTS - ROOF, WINDSHIELD and COWL REF. NO. KUBOTA P/N CODE NO. QTY. DESCRIPTION 77700-05417 KF2-01 METAL ROOF WITH TRIM & HEADLINER 77700-05418 KF2-02 WINDSHIELD WITH RUBBER 77700-05452 9PWA20/24-PG WIPER ARM ASSEMBLY, PANTOGRAPH 20-24”...
  • Page 14 P. 14 of 14 F5206 F-SERIES CAB SERVICE PARTS - DOORS REF. NO. KUBOTA P/N CODE NO. QTY. DESCRIPTION 77700-05424 KF2-07L DOOR ASSEMBLY (STEEL), LEFT 77700-05425 KF2-07R DOOR ASSEMBLY (STEEL), RIGHT 77700-05447 9SW-KF2L SLIDING DOOR WINDOW, LEFT 77700-05448 9SW-KF2R SLIDING DOOR WINDOW, RIGHT...
