  • Page 1 " " SERIAL NO. 21300001 AND UP For RTV-X900, RTV-X1100 & RTV-X1120 Series Estimated installation time: 20 min. OM 0428BR-A MANUAL PART NUMBER 77700-04889 09/13...

  • Page 3: Table Of Contents

    TABLE OF CONTENT SPECIFICATIONS ..........................3 INTRODUCTION – To the Purchaser & Dealer ..................4 SAFETY PRECAUTIONS ........................5 Before Operation..........................5 Notice ..............................6 Subframe & Rotary Broom ........................ 6 Before Operation ........................ 6 Rotary Broom & Subframe Operation ................7 The Vehicle ........................
  • Page 4 TABLE OF CONTENT MAINTENANCE ............................ 18 Trouble shooting ..........................18 Uneven Wear of the Brush ....................18 The Brush Bounces ......................18 Rear Debris Being Thrown Back ..................18 Debris Left on the Ground ....................18 Storage ............................20 Maintenance ..........................20 Hardware ..........................

  • Page 5: Specifications

    SPECIFICATION Features and Specifications V5260 Category Overall width 75 3/8" Overall height 19 3/4" (wheel on the ground) Overall length 36 3/8" Hydraulic angling (0 to 25 degrees) Standard Working width at maximum angle 50 1/2" Primary drive Hydraulic Hitch system...

  • Page 6: T O The Dealer

    INTRODUCTION O THE URCHASER O THE EALER All products are designed to give safe, Give this manual to the owner upon delivery of dependable service if they are operated and the equipment. maintained according to instructions. Read understand this manual before operation, and keep it in your files for future &...

  • Page 7: Before Operation

    SAFETY PRECAUTIONS SAFETY FIRST This symbol, the industry's "Safety Alert Symbol", is used throughout this manual and on labels on the machine itself to warn of the possibility of personal injury. Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use this rotary broom.

  • Page 8: Notice

    SAFETY PRECAUTIONS - continued OTICE A safe operator is the best assurance against accidents. All operators, no matter how experienced they may be, should read this operator's manual and all other related manuals before attempting to operate the rotary broom. Please read the following section and pay particular attention to all safety recommendations contained in this manual and those labeled on the rotary broom and on the vehicle.

  • Page 9: Rotary Broom & Subframe Operation

    SAFETY PRECAUTIONS - continued Rotary Broom & Subframe Operation 1. Before leaving the vehicle unattended, take 10. Do not run the engine indoors except when possible precautions. Park starting engine transporting vehicle/rotary broom on level ground, place attachment in or out of building. Carbon the transmission in neutral, set the parking monoxide gas is colorless, odorless and brake, disengage the hydraulic control,...
  • Page 10 SAFETY PRECAUTIONS - continued 20. Never allow anyone to operate the rotary 32. Slow down before you change directions broom until they have read the manual on any slope. completely and are thoroughly familiar with 33. Never stand alongside of the rotary broom basic vehicle and rotary broom operation.

  • Page 11: The Vehicle

    SAFETY PRECAUTIONS - continued EHICLE General Information 11. Fill fuel tank outdoors with extreme care. Never fill fuel tank indoors. Replace fuel 1. Read the operator's manual carefully before cap securely and wipe up spilled fuel. using vehicle. Lack of operating knowledge can lead to accidents.

  • Page 12: Maintenance

    SAFETY PRECAUTIONS - continued AINTENANCE 10.Do not modify or alter this rotary broom or any ALWAYS USE GENUINE PARTS WHEN of its components or operating functions. If you REPLACEMENT PARTS ARE REQUIRED have questions concerning modifications, 1. Keep the vehicle and rotary broom consult with your dealer.

  • Page 13: Decals

    DECALS Replace Immediately if Damaged V5291 77700-0893 (2500905) 70060-45006 (2500584) 70060-03763 (660988) 70060-02232 (2500484) 70060-02833 (664391) 70060-03033 (658710) 77700-01139 (2500615) OM 0428BR-A...

  • Page 14: Assembly

    ASSEMBLY OTARY BROOM NSTALLATION NOTE: Raise the rotary broom to remove it from the wooden box and set the parking stands in the position where they touch the ground and secure with 1/4" x 1 3/4" round wire lock pins. Attaching Rotary Broom to RTV (Figure 1) 1.

  • Page 15: Installation Of The Gauge Wheels

    ASSEMBLY Installation of the Gauge Wheels (Figure 2) 1. Insert assembled wheel adjustments (item 1) into the left and right wheel supports (item 2) and secure in place to the maximum height with a round wire lock pin (item 3). 2.

  • Page 16: Operation

    OPERATION ENERAL REPARATION Adjusting Vehicle Suspension IMPORTANT It's recommended to set the front suspension The V5240 Cooling unit is REQUIRED unless the setting of the vehicle to its maximum stiffness vehicle is already equipped with an original cooling when using this equipment since a lower unit.

  • Page 17: Brush-To-Ground Contact

    OPERATION IMPORTANT: Always use the float position when working with the broom (refer to the Owner Manual of the hydraulic control (V5232)). Brush-to-Ground Contact (Figure 4) 4. Raise the broom and move back the vehicle NOTE: This adjustment is needed once to then turn off the engine.

  • Page 18: Gauge Wheels Adjustment

    OPERATION Gauge Wheels Adjustment (Figure 5) To adjust the height of the wheel (1/2" at a Figure 5 time, from 3" minimum to 7" maximum) slide the inner tube upward or downward, as needed, and insert the round wire lock pin in the open hole.

  • Page 19: Optimum Performance

    OPERATION PTIMUM ERFORMANCES The hydraulic motors of the rotary broom must have a breaking in period. If it is not IMPORTANT: respected, the warranty could be voided. The breaking in period must follow these steps: 1- 15-30 minutes of operation without any load and at half speed. 2- Check for unusual noises coming from the motors.

  • Page 20: Maintenance

    MAINTENANCE ROUBLESHOOTING Uneven Wear of the Brush Debris Left on the Ground • Make sure there is no debris wrapped The travel speed of the vehicle is too fast. Slow down. around the brush. • Check if the tilt plate is adjusted properly (see page 15), if not using the gauge wheels.
  • Page 21 MAINTENANCE PROBLEM CORRECTIVE MEASURE 2. The brush is turning in • Check that the hoses are connected correctly to the hydraulic block reverse and reverse their position if necessary. • Check the viscosity of the hydraulic oil; • Check hydraulic pump oil level and add some if needed; •...

  • Page 22: Storage

    MAINTENANCE TORAGE AINTENANCE Before storing the rotary broom, certain ALWAYS USE GENUINE PARTS WHEN precautions should be taken to protect it REPLACEMENT PARTS ARE REQUIRED. from deterioration. 1. Avoid exposing broom bristles to direct sunlight 1. Clean the rotary broom thoroughly. for long periods to avoid damage.

  • Page 23: Brushes Replacement

    MAINTENANCE Brushes Replacement (Figures 7-7a) When the brushes reach a 12" in diameter, 5. Figure 7: Remove the brushes by sliding them it is necessary to replace them in order to towards the outside of the brush support maximize the performance of your broom. (item 11).

  • Page 24: Lubrication

    MAINTENANCE Lubrication Use a grease gun and oiler and grease and lubricate as follows: DESCRIPTION TIME INTERVAL LUBRICATION REQUIRED All pivot points 8 hours of operation Use a good quality multipurpose lubricant Bearing 8 hours of operation Grease each bearing Wheel bracket 8 hours of operation Use a good quality multipurpose lubricant...

  • Page 25: Hydraulic Diagram

    HYDRAULIC DIAGRAM YDRAULIC IAGRAM OM 0428BR-A...

  • Page 26: Parts

    PARTS NTRODUCTION All parts are illustrated in "exploded views" which show the individual parts in their normal relationship to each other. Reference numbers are used in the illustrations. These numbers correspond to those in the "Reference Number" (REF) column, and are followed by the description and quantity required. All reference to right and left, forward or rearward, is from the operator seat facing the steering wheel.

  • Page 27: Brush Support

    PARTS RUSH UPPORT ESCRIPTION Brush Support 77700-02242 669648 Bushing 77700-02243 669650 Key 5/16" X 5/16" X 1" 77700-02638 664780 Retaining plate 77700-01653 669133 "Z" brush polypropylene 6 3/8" x 18" thin stalk 77700-02257 3800074 "Z" brush 100% steel 6 3/8" x 18" 70060-02105 3800056 Brush set (27) - 100% polypropylene 6 3/8"...

  • Page 28: Rotary Broom Assembly

    PARTS OTARY ROOM SSEMBLY OM 0428BR-A...
  • Page 29 PARTS OTARY ROOM SSEMBLY ESCRIPTION Brush Cover and knurlned riveted nuts 77700-02249 669661 Rear reinforcement and knurled riveted nuts 77700-04928 670610 Right lateral plate 77700-04927 670609 Left lateral plate 77700-04926 670608 Tilt plate and bushings 77700-02247 669656 Tilt adjustment rob 77700-02245 669653 Spacer...

  • Page 30: Hydraulic Components

    PARTS YDRAULIC OMPONENTS OM 0428BR-A...
  • Page 31 PARTS YDRAULIC OMPONENTS ESCRIPTION Hydraulic cylinder 2" x 5" 70001-00871 665433 - Seal kit 70001-00872 665434 - Pin 3/4" x 2 1/2" PTD 70001-00795 665235 - Cotter pin 3/16" x 1 1/4" 77700-01667 1500012 Hydraulic motor 162 cc 77700-02258 3910091 - Seal kit 77700-03031 3900223...

  • Page 32: Lawn Dethatching Wheel Kit

    PARTS ETHATCHING HEEL ESCRIPTION Gauge wheel ass'y 70060-02102 666993 Wheel adjustment 70060-01984 666943 Wheel bracket 70060-01985 666944 Wheel ass'y 70060-01987 3800055 Wheel bushing 70060-01986 666945 Hex bolt 1/2"NC x 5" gr.5 PTD 75599-01500 0100082 Serrated flange nut 1/2"NC PTD 70060-01992 0900046 Structure flat washer 3/4"...

  • Page 33: Available Option

    AVAILABLE OPTIONS BED-MOUNTED WATER TANK W/WAND & REEL KIT V5292 60" DUST SUPPRESSION NOZZLE KIT MARKERS with DUST DEFLECTOR V4496 V5250 OM 0428BR-A...

  • Page 34: Torque Specification Table

    TORQUE SPECIFICATION TABLE GENERAL SPECIFICATION TABLE Use the following torques when special torques are not given NOTE: These values apply to fasteners as received from supplier, dry, or when lubricated with normal engine oil. They do not apply if special graphited or moly sidulphide greases or other extreme pressure lubricants are used. This applies to both UNF and UNC threads. SEE Grade No.
  • Page 36 Printed in Canada...
