June 2021© Kubota Fx80 Series ROPS Cab Installation Manual
Kubota Fx80 Series ROPS Cab
** Shown with optional equipment
Kubota Fx80 Series ROPS Cab
This ROPS cab is designed and built to fit the Kubota F2880, F3080, and F3680.
Designed and Built by:
Tektite Manufacturing Inc:
427 Buffalo Street
P.O. Box 639
Winkler, MB
R6W 4A8
Canada
PH: 204-331-3463
Fax: 204-331-4159
sales@tektite.ca
www.tektite.ca
One year standard product warranty provided by Tektite.

Advertisement

loading
Need help?

Need help?

Do you have a question about the ROPS Cab F 80 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kubota ROPS Cab F 80 Series

Summary of Contents for Kubota ROPS Cab F 80 Series

  • Page 1 Kubota Fx80 Series ROPS Cab ** Shown with optional equipment Kubota Fx80 Series ROPS Cab This ROPS cab is designed and built to fit the Kubota F2880, F3080, and F3680. Designed and Built by: Tektite Manufacturing Inc: 427 Buffalo Street P.O.
  • Page 2 DO NOT PROCEED FURTHER UNTIL YOU HAVE READ THE INFORMATION BELOW 1) Always wear personal protective equipment 2) A minimum of two people is necessary to safely install the cab 3) This ROPS cab is heavy. A lift assist device such as an overhead hoist or high lift forklift is required.
  • Page 3 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual Tektite Manufacturing Incorporated thanks you for purchasing a Kubota Fx80 series ROPS cab! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.
  • Page 4 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual Parts List Standard Cab: Description Bolt, Flange, ½” x 1 ½”, Gr. 8, Yellow Nut, Flange, Serrated, ½”, Gr. 8, Yellow Under seat upholstery Floor mat, operator platform L&R Push button fasteners Bolt, Hex, ½”...

  • Page 5: Air Conditioning

    June 2021© Kubota Fx80 Series ROPS Cab Installation Manual Air Conditioning Description Bolt, Flange, 3/8” x 1 ½”, Gr. 8, Yellow Nut, Flange, Serrated, 3/8”, Gr. 8, Yellow Bolt, Hex, 3/8” x 2”, Gr. 8, Yellow Bolt, Hex, 3/8” x 3 ½”, Gr. 8, Yellow 5/16”...
  • Page 6 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual...

  • Page 7: Installation Instructions

    June 2021© Kubota Fx80 Series ROPS Cab Installation Manual Installation Instructions: 1. Remove two-post ROPS from machine. Save fasteners to re-use later. Remove the tractor seat. 2. Remove the left and right floor skid pads at the front of the operator platform.
  • Page 8 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual October 2019© Kubota Fx80 Series ROPS Cab Installation Manual 4. On the right side, centre punch and drill out the two fasteners that are there to a ½” diameter hole. These will be the front right bracket mounting holes.
  • Page 9 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual 6. Take the 6 ¼” piece of 180° weather stripping for the differential lock pedal. Slide the o- rubber onto the inside edge of sheet metal in the slot. This will provide a better seal for this pedal.
  • Page 10 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual 10 For the front right slot, take the two 4 ½” pieces of 180° weather stripping. Slide the o- rubber onto each side of the slot. 11. For the rear left slot, take the two 3 ½” pieces of 180° weather stripping. Slide the o-rubber pieces onto each side of the slot.
  • Page 11 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual 16. Using a lift strap or chains, connect the two lift bolts to an over head hoist or forklift and lift the cab off of the shipping pallet a couple feet.
  • Page 12 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual 21. Once all fasteners have been started, torque the rear bracket bolts to 102 ft-lbs. The ½” fasteners can be torqued to 102 ft-lbs. The cab isolator fasteners can be torqued to 240 ft-lbs.
  • Page 13 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual Proceed with the following steps if the cab is equipped with a heater. 30. Drain the engine antifreeze. 31. NOTE: On the cab, the heater hose located against the glass is the pressure hose, and the hose furthest away is the return hose.
  • Page 14 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual 33. On the right side of the water pump there is a cap. Remove the cap. Slide the ½” ID heater hose onto the steel pipe and attach with a hose clamp provided. Insert the 1/2-3/8 reducer at the end of the hose.
  • Page 15 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual 39. Disconnect the engine drive shaft, three bolts in order to remove the factory drive belt. 40. Replace the factory drive belt with the longer belt provided in the kit. 41. Take the compressor mounting bracket and position it where the alternator and tensioner were located.
  • Page 16 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual 42. Take the compressor and position it onto the mounting bracket. Using one 3/8” x 1 ½” flange bolt and nut for the rear ear fastener, sliding the bolt in, in the direction shown below through the rear compressor stiffener.
  • Page 17 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual 43. Slip the short v-belt onto the rear groove of the compressor. Slip the long belt onto the front groove of the compressor. 44. Take a 3/8” x 1 ½” flange bolt and nut and start the tensioner fastener on the compressor.
  • Page 18 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual 49. Connect the white compressor clutch wire to the compressor. 50. Re-install the engine drive shaft. 51. On the right side of the engine, note the location of the fuse mount on the outside of the radiator shroud.
  • Page 19 June 2021© Kubota Fx80 Series ROPS Cab Installation Manual 53. Take the hoses going to the overflow bottle and re-route as shown in the photo above. The bottom hose will hang below. NOTE: At this stage, the air conditioning system is ready for pressurization. A licensed air conditioner installer must perform the install.
  • Page 20 June 2021© Kubota Fx80 Series ROPS Cab Operator Manual Kubota Fx80 Series Cab ** Shown with optional equipment Kubota Fx80 Series Cab This ROPS cab is designed and built to fit the Kubota F2880, F3080, and F3680. Designed and Built by: Tektite Manufacturing Inc: 427 Buffalo Street P.O.
  • Page 21 June 2021© Kubota Fx80 Series ROPS Cab Operator Manual Tektite Manufacturing Incorporated thanks you for purchasing a Kubota Fx80 series ROPS cab! Tektite has worked very hard to design and build this ROPS product and we hope that it provides you with many years of ROPS protection.
  • Page 22 June 2021© Kubota Fx80 Series ROPS Cab Operator Manual Tektite Limited Warranty Tektite Manufacturing Inc. (“Tektite”) warrants to the original purchaser (the “Claimant”), that Tektite products will be free from defective materials or workmanship, under normal use and service, for a period of (1) full year from the original invoice date.

  • Page 23: Safety Precautions

    June 2021© Kubota Fx80 Series ROPS Cab Operator Manual Safety Precautions Safety First Read these instructions carefully. It is essential that you read the instructions and safety regulations before you attempt to assemble or use the features that are on this cab/ROPS.

  • Page 24: Operating Safety

    June 2021© Kubota Fx80 Series ROPS Cab Operator Manual General Safety 1. Never let an unqualified or untrained driver operate the mower. 2. Keep a fire extinguisher, with ABC rating securely fastened in the ROPS. Maintain it and be familiar with its use.
  • Page 25 June 2021© Kubota Fx80 Series ROPS Cab Operator Manual Safe Operation on Rough Terrain 1. Drive the mower slowly on hillsides and curves to eliminate the danger of tipping. Avoid slopes which are too steep for safe operation. Avoid sharp uphill turns.
  • Page 26 June 2021© Kubota Fx80 Series ROPS Cab Operator Manual 9. Use your turn signals, checking for traffic well in advance of turning. If the mower is not equipped with turn signals and law requires them, install them prior to operating on or near public roads.
  • Page 27 June 2021© Kubota Fx80 Series ROPS Cab Operator Manual Operating Instructions Important The following section locates, identifies and briefly describes the functions of all cab controls. All operators should familiarize themselves with control location and function prior to operating the mower. Failure to do so may result in unsafe operation of the mower and possible injury or death to operators and bystanders.
  • Page 28 June 2021© Kubota Fx80 Series ROPS Cab Operator Manual High position: On Note: indicator light activates when wiper is on. 3. Front Work Light Rocker Switch (optional) Low position: Off High position: On Note: indicator light activates when work lights are on.
  • Page 29 June 2021© Kubota Fx80 Series ROPS Cab Operator Manual 4. Fan Rotary Switch (optional) Indicator mark above switch indicates whether fan is operational or not. 5. Temperature Control Rotary Switch (optional) Indicator mark at lower left corner indicates current temperature setting. Rotate to increase heat output or to decrease heat output of heating system.
  • Page 30 Index Service Part # File Name Description A00-0001 DLP-HANDLE Outside Push Button Handle A00-0002 LEFT-LATCH Suicide Door Left Latch A00-0013 TEKT-0009 5MM Bushing A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4"...
  • Page 31 Index Service Part # File Name Description A00-0001 DLP-HANDLE Outside Push Button Handle A00-0003 RIGHT-LATCH Suicide Door Right Latch A00-0013 TEKT-0009 5MM Bushing A00-0018 STEP-BOLT1-4X1-1-2 Step Bolt, 1/4" x 1 1/2", MB A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4"...

  • Page 32: Windshield Assembly

    Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0014 TEKT-0092 Thick Bushing A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD K01-0004 KUF2880-009 Windshield Glass K01-0010 KUF2880-055 Windshield Seal Tektite Manufacturing Inc. SCALE 0.200 24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada Req'd:...
  • Page 33 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0020 STEP-BOLT1-4X1-1-4 Step Bolt, 1/4" x 1 1/4", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0033 315-080 Rear Wiper Shaft Grommet A00-0043 WWF-MOTOR WWF Wiper Motor, 1"...
  • Page 34 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0044 TEKT-ASM-002 Side Window Hinge Weldment A00-0045 TEKT-0004 Side Window Slider Bracket A00-0057 TEKT-0020MIR Side Window Latch, L60776 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD...
  • Page 35 Index Service Part # File Name Description A00-0013 TEKT-0009 5MM Bushing A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0045 TEKT-0004 Side Window Slider Bracket A00-0046 TEKT-ASM-002R Side Window Hinge Right A00-0056 TEKT-0020 Side Window Latch, L60775 A00-0058 CARRIAGE_BOLT-5-16X1 Bolt, Carriage, 5/16"x 1", YD...
  • Page 36 Index Service Part # File Name Description A00-0006 TEKT-0074 Cabin Air Filter A00-0016 TEKT-0075 Domelight LED A00-0017 305-1002 Panto Mount Plate A00-0025 BALL-LOUVER 2 1/2" Ball Louver A00-0026 OSCILLATING-FAN Oscillating Fan A00-0038 TEKT-0076 3" Plug A00-0055 TEKT-0019 Fir Tree Fastener A00-0070 REID-KBP-262-KBP-265 Knob, Knurled, 1/4"...
  • Page 37 Index Service Part # File Name Description A00-0019 STEP-BOLT1-4X1 Step Bolt, 1/4" x 1", MB A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0025 BALL-LOUVER 2 1/2" Ball Louver A00-0028 TEKT-0088 Red Dot Drier A00-0081 KUF2880-HEADLINER-REV1 Headliner A00-0105 R-2300-2_090902 Heater A/C Blower Unit, 2300 A00-0171 TEKT-0089 Binary Switch...
  • Page 38 Index Service Part # File Name Description A00-0076 TEKT-0026 1/4" Panel Nut A00-0089 TEKT-0059 Heater Core A00-0090 TEKT-0065 Upper Blower Housing A00-0091 TEKT-0066 Blower Housing Lower A00-0100 FLANGE_BOLT_1-4X1-2 Flange Bolt, 1/4" x 1/2", YD A00-0157 TEKT-ASM-015 Bottom Heater Shroud Weldment A00-0158 TEKT-ASM-014 Top Heater Shroud Weldment...

  • Page 39: Roof Assembly

    Index Service Part # File Name Description A00-0008 TEKT-0077 Front Turn Signal Light LED, Amber A00-0009 TEKT-0079 Oval LED Light Grommet A00-0010 TEKT-0078 Round Grommet, LED Light A00-0011 TEKT-0080 Round Turn Light A00-0078 RED-DOT-CONDENSOR Red Dot Condensor 77R1602 K01-0015 KUF2880-ROOF Roof Tektite Manufacturing Inc.
  • Page 40 Index Service Part # File Name Description A00-0166 TEKT-0103 Condensor Fan A00-0220 TEKT-0101 Base Condenser Coil A00-0221 TEKT-0102 Condensor Assembly Steel Shroud Tektite Manufacturing Inc. 24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada Req'd: CNC: Description: Notice of Confidentiality Condensor Assembly Breakdown Tolerances: This material is property of Tektite Manufacturing...

  • Page 41: Assembly Accessories

    Index Service Part # File Name Description KUF2880-ASM-025 Cab Weldment A00-0021 FLANGE-NUT-1-4 Flange Nut, 1/4", YD A00-0023 FLANGE_BOLT_1-4X3-4 Flange Bolt, 1/4" x 3/4", YD A00-0059 FLANGE-NUT-5-16 Flange Nut, 5/16", YD A00-0061 TEKT-0021 Striker Mounting Plate A00-0084 TEKT-0070 Gas Shock A00-0085 TEKT-0069 Gas Shock Stud A00-0101...
  • Page 42 Index Service Part # File Name Description A00-0055 TEKT-0019 Fir Tree Fastener A00-0063 LEFT-CAB-SWITCHPLATE Left Switchplate A00-0064 LEFT-CAB-SWITCHPLATE-DECAL Left Switchplate Decal A00-0065 TEKT-ASM-005 On-Off Switch w/Lens A00-0066 TEKT-ASM-006 On-Off-On Rocker No Lens A00-0067 TEKT-ASM-007 Mom-Off-Mom Rocker Switch Tektite Manufacturing Inc. SCALE 1.000 24157 Hwy 3, Box 639, Winkler MB, R6W 4A8, Canada...
  • Page 43 Index Service Part # File Name Description A00-0007 FAN-SWITCH 4-Position Fan Switch A00-0054 TEKT-0018 Fan Speed Control Knob A00-0055 TEKT-0019 Fir Tree Fastener A00-0065 TEKT-ASM-005 On-Off Switch w/Lens A00-0252 TEKT-0117 Water Valve Directly on Switch A00-0253 TEKT-0119 Right Switchplate Decal, 2014 Update A00-0282 SCREW-3-16X3-4 Screw, Self-Tap, 3/16"...
