Summary of Contents for Furniture of America CM7941BLTR
- Page 1 R E V . 1 5 - 1 1 - 2 7...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Front Panel Bolt 5/16”x1-3/8” #B x 8 pcs #2 x 2 pcs Flat Washer...
- Page 4 #A x 8 pcs #B x 8 pcs #C x 8 pcs Align the two side panels (#2) with the pre-drilled holes on the back of the front panel (#1). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#A) and then the flat washer (#B) onto the Turn right (clockwise) to tighten...
- Page 5 Place the bottom panel (#6) over the assembled slats (#4). Insert the center panel (#5) between the space of the front panel (#1) AND the rear panel (#3). ASSEMBLY IS COMPLETED Page 5 of 5...
