Assembly Instructions
CM7911
Set Includes Pre-Assembled Nightstand
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
Allen Wrench
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
Wrench
products, two persons are recommended.
(Not Included)
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 7
Rev.14-05-30
Advertisement
Table of Contents
Related Manuals for Furniture of America Francesca CM7911
Summary of Contents for Furniture of America Francesca CM7911
- Page 1 Assembly Instructions CM7911 Set Includes Pre-Assembled Nightstand ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Wrench products, two persons are recommended.
- Page 2 Page 2 of 7...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List #1 x 1 pc #2 x 1 pc Dresser Mirror #3 x 2 pcs #4 x 1 pc Mirror Support Rail Headboard...
- Page 4 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling the product to avoid any potential injury and/or damage, especially with the fragile nature of the mirror.
- Page 5 The machine screw (#H) is already assembled onto the knob (#K) from the factory. Remove the machine screw (#H) using a Phillips screwdriver from the knob (#K) and secure the knob (#K) onto the door of the dresser (#1) using the same screw. #H x 1 pc #K x 1 pc Turn right (clockwise) to tighten...
- Page 6 The two mirror support brackets (#3) are already attached behind the dresser. Position the mirror support brackets (#3) vertically to align with the pre-drilled hole of the dresser (#1) AND the mirror (#2). #A x 8 pcs II. Prepare 6 bolt assemblies by #D x 8 pcs inserting FIRST the lock #E x 8 pcs...
- Page 7 This is an optional step to assemble the headboard with the bed frame (sold separately). Align the holes of the completed headboard with the holes of the bed frame. Insert the bolts and washers according to diagram below. #B x 4 pcs #D x 8 pcs #E x 8 pcs #F x 4 pcs...
