- Page 5 1. Place the left/right side rails (#1,2) onto a protected surface, then align the headboard support (#7,8) as displayed and insert a bolt (#C). Secure using the Allen wrench. 2. Align the rail support legs (#14) to the end of the side rails (#1,2) with the headboard supports (#7,8).
- Page 6 1. Align the headboard up tube frame (#10) to the 4. Apply a flat washer (#1) onto the bolt top of the headboard supports (#7,8) then insert (#D), then place the 2 bolts (#D) into each end. Align the headboard slats (#16).
- Page 7 1. Prepare 6 screws by inserting a flat washer (#H) onto the screws (#G). Place the shelf (#13) on top, then insert the screw assemblies. Secure using a screwdriver. 2. Place the headboard panel (#12), then insert a bolt (#C) into each hole from the back.
- Page 8 1. Align the wheels (#15) to the holes along the sides of the side rails. Insert 2 bolts (#B) into each. Secure using the Allen wrench (#F). 2. Align the slat support legs (#17) to the holes along the center of the slats. From above insert a bolt (#B).
