ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7941T
DIFFICULT
Page 1 of 5
Tools Required for Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
(Included)
(not Included)
Rev.14-06-18
Advertisement
Table of Contents
Related Manuals for Furniture of America CM7941T
Summary of Contents for Furniture of America CM7941T
- Page 1 Assembly Instructions CM7941T ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 6 pcs Headboard Bolt 5/16”x1-3/8” #B x 6 pcs #2 x 1 pc Flat Washer Left H/Board Leg...
- Page 4 #A x 6 pcs #B x 6 pcs Backside #C x 6 pcs Align the left HB leg (#2) with the pre-drilled holes of the headboard (#1). Prepare 3 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#A) and then the flat washer (#B) onto the Note: Right and SAME bolt (#A), in that order.
- Page 5 Align the 4 slats (#6) with the pre-drilled holes of the side rails (#5). Secure 2 screws (#E) onto the ends of the slat (#6) using a Phillips screwdriver to tighten them with the side rails (#5). Repeat the process to assemble the remaining 3 slats (#6) onto the side rails (#5).
