Summary of Contents for Eizo FLEXSCAN S2232W
- Page 1 Please read PRECAUTIONS, this User’s Manual and Setup Guide (separate volume) carefully to familiarize yourself with safe and effective usage. • Please read the Setup Guide (separate volume) • The latest User’s Manual is available for download from our site: http://www.eizo.com...
- Page 2 EIZO NANAO CORPORATION’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.
-
Page 3: Notice For This Monitor
Notice for this monitor This product is suited to creating documents, viewing multimedia content, and other general purposes. This product has been adjusted specifically for use in the region to which it was originally shipped. If the product is used outside the region, it may not operate as specified in the specifications. This product may not be covered by warranty for uses other than those described in this manual. - Page 4 Cleaning Attention • Never use any solvents or chemicals, such as thinner, benzene, wax, alcohol, and abrasive cleaner, which may damage the cabinet or LCD panel. NOTE • Optional ScreenCleaner is recommended for cleaning the panel surface. [LCD Panel] • Clean the LCD panel with a soft cloth such as cotton cloth or lens cleaning paper. •...
-
Page 5: Table Of Contents
● To use ScreenManager Pro for LCD ....13 -17 Setting Language [Language] ...... 6 - Screen Adjustment ........1 Digital Input ............1 -18 Setting EIZO logo display ON/OFF ....6 Analog Input ............1 -19 Resuming the Default Setting [Reset] ..7 - Color Adjustment ........... 17 ● To reset color adjustment values ...... 27 ●... - Page 6 CONTENTS Chapter Reference ......... -1 Attaching an Arm ........... - Folding the EZ-UP stand ....... 5-3 Specifications ..........6 - Glossary ............ - Preset Timing ..........7 TCO’0 ............8 FCC Declaration of Conformity ......9 Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor ..........0 Hinweis zur Ergonomie ........0 CONTENTS...
-
Page 7: Chapter 1 Features And Overview
Chapter 1 Features and Overview Thank you very much for choosing an EIZO color LCD monitor. 1-1 Features • 22” wide format LCD Applicable to WSXGA+ (1680×1050) (S2232W)/ 22” wide format LCD Applicable to WUXGA (1920×1200) (S2242W)/ 24” wide format LCD Applicable to WUXGA (1920×1200) (S2432W) •... -
Page 8: Controls And Functions
Used to attach the option speaker (i·Sound L3). (May not allowed to attach the option speaker depending on the stand type.) mounting holes * ScreenManager is an EIZO’s nickname of the Adjustment menu. See page 10 for how to use. ®... -
Page 9: Compatible Resolutions/Frequencies
1- Compatible Resolutions/Frequencies The monitor supports the following resolutions. Analog Input SW SW/SW Resolution Frequency Mode Dot Clock ~10MHz Dot Clock ~0.MHz √ √ 640 × 480 ~75 Hz VGA, VESA √ √ 720 × 400 70 Hz VGA TEXT √ √ 800 × 600 ~75 Hz VESA √... -
Page 10: Functions And Basic Operation
1- Functions and Basic Operation To adjust the screen and color Main menu (Refer to page 1 for operation) Analog input only [At analog signal input] Screen Adjustment Page 1 (Automatic Adjustment) ● To adjust flickering and position [Screen] ……………………………… see page 14 [At digital signal input] ● To adjust color gradation automatically [Range] ……………………………… see page 16 Screen Adjustment Page 1 (Advanced Adjustment) [At analog signal input] [At digital signal input] • The Adjustment menu and the FineContrast mode name cannot be displayed at the same time. - Page 11 20 ● [DDC/CI] ……………………………… see page 26 Turning off the audio output at Power Saving ● Setting EIZO logo display ON/OFF … see page 26 mode [Power Save] ………………… see page 20 ● Adjusting the DVI Input Level [DVI Input Level] ……………………… see...
- Page 12 Basic operation of Adjustment menu [Displaying Adjustment menu and selecting function] (1) Press . The Main menu appears. (2) Select a function with , and press . The Sub menu appears. (3) Select a function with , and press . The adjustment/setting menu appears. (4) Adjust the selected item with , and press .
-
Page 13: Chapter Settings And Adjustments
Chapter Settings and Adjustments -1 Utility Disk An “EIZO LCD Utility Disk” (CD-ROM) is supplied with the monitor. The following table shows the disk contents and the overview of the software programs. ● Disk contents and software overview The disk includes software programs for adjustment, and User's Manual. Refer to “Readme.txt” or the “read me” file on the disk for software startup procedures or file access procedures. -
Page 14: Screen Adjustment
NOTE • For how to open and contents of • For how to open and contents of Load the "EIZO LCD Utility Disk" to your PC, and then start the the screen adjustment pattern files, the screen adjustment pattern files, "Screen Adjustment Utility"... -
Page 15: To Eliminate Vertical Bars [Clock]
Perform the auto adjustment again with the analog screen adjustment pattern displayed. ● To adjust flickering, screen position, and screen size automatically [Screen] (1) Display Pattern 1 in full screen on the monitor using the “Screen Adjustment Utility” or the screen adjustment pattern files. (2) Choose <Screen> from the <Auto Adjustment> menu, and press The <Auto Adjustment> menu appears. (3) Choose <Execute>... -
Page 16: To Correct Screen Position [Position]
● To correct screen position [Position] NOTE NOTE • Since the number of pixels and the • Since the number of pixels and the (1) Choose <Position> from the <Screen> menu, and press pixel positions are fixed on the LCD pixel positions are fixed on the LCD The <Position>... -
Page 17: Color Adjustment
- Color Adjustment ● To select the display mode (FineContrast mode) FineContrast allows you to select the best display mode easily according to the monitor’s application. FineContrast mode Mode Purpose Custom Available to change all setting values. Suitable for color matching with sRGB compatible sRGB peripherals. Suitable for displaying texts for word processing or Text spreadsheets. -
Page 18: To Perform Advanced Adjustments
● To perform advanced adjustments Attention Attention • Wait 30 minutes or more from • Wait 30 minutes or more from Independent setting and saving of color adjustment are available for each monitor power on before starting the monitor power on before starting the FineContrast mode. -
Page 19: To Adjust The Color Temperature [Temperature]
● To adjust the color temperature [Temperature] NOTE NOTE • You cannot adjust the value if the • You cannot adjust the value if the The color temperature can be adjusted. The color temperature is normally used icon is not displayed, depending on icon is not displayed, depending on to express the hue of “White”... -
Page 20: To Adjust The Hue [Hue]
● To adjust the hue [Hue] Attention Attention • This function does not enable to • This function does not enable to This function allows you to adjust the hue. If you set the hue to a high value, display every color gradation. display every color gradation. the image turns greenish. -
Page 21: Setting On/Off For The Automatic Brightness Adjustment Function [Auto Ecoview]
NOTE NOTE -6 Setting On/Off for the automatic • Be careful not to block the sensor on • Be careful not to block the sensor on brightness adjustment function the lower side of the monitor when the lower side of the monitor when [Auto EcoView] using the Auto EcoView function. using the Auto EcoView function. -
Page 22: Turning Off The Monitor Automatically [Off Timer]
-8 Turning off the monitor automatically [Off Timer] This function allows you to switch the setting to turn off the monitor automatically after a specified time has passed at the power saving mode. Adjustable range: Disable, Enable (0, 1, 2, 3, 5, 10, 15, 20, 25, 30, 45 min, 1-5h) (1) Choose <PowerManager>... -
Page 23: Screen Size Selection
-10 Screen Size Selection ● To change screen size [Screen Size] The image with the resolution other than the recommended resolution is displayed in full screen automatically. You can change the screen size by using <Screen Size> from <Others> menu. Menu Function Displays an image in full screen. Images are distorted in Full Screen some cases because the vertical rate is not equal to the (default setting) -
Page 24: Setting Adjustment Menu Display
-11 Setting Adjustment Menu Display ● To update menu settings [Menu Size/Menu Position/Menu Off Timer/Translucent] Menu Size Change the Adjustment menu size using the following procedure. (1) Choose <Others> from the Adjustment menu, and press (2) Choose <Menu Settings> from the <Others> menu, and press (3) Choose <Menu Size> from the <Menu Settings> menu, and press The <Menu Size>... -
Page 25: Setting Orientation
Attention Attention -1 Setting Orientation • Be sure that the cables are correctly • Be sure that the cables are correctly ● To set the orientation of the Adjustment menu [Orientation] connected. connected. This function allows you to change the orientation of the Adjustment menu NOTE NOTE • For using the monitor with •... -
Page 26: Enabling/Disabling Ddc/Ci Communication
EIZO logo. (1) Press to turn off the monitor. (2) Press holding down to turn on the monitor. The EIZO logo display setting is toggled by performing the operation in step 2. Chapter 2 Settings and Adjustments... -
Page 27: Resuming The Default Setting [Reset]
-19 Resuming the Default Setting [Reset] Attention Attention • After resetting, you cannot undo the • After resetting, you cannot undo the There are two types of Reset. One is to reset the color adjustment only to the operation. operation. default settings, and the other is to reset all the settings to the default settings. ●... -
Page 28: Chapter Connecting Cables
Chapter Connecting Cables -1 Connecting Two PCs to the Monitor Two PCs can be connected to the monitor through the DVI-D and the D-Sub mini 15 pin connector on the back of the monitor. Connection examples D-Sub mini 15-pin Connector DVI-D connector Digital Analog To PC 1 To PC 2 D-Sub mini DVI-D connector... -
Page 29: To Set Input Signal Selection [Input Signal]
● NOTE To set input signal selection [Input Signal] • When “Auto” is selected for <Input The monitor recognizes the connector through which PC signals are input. Signal>, the monitor’s power-saving When either PC is turned off or enters the power-saving mode, the monitor function works only when the two PCs are in the power-saving mode. -
Page 30: Connecting Peripheral Usb Devices
(2) Windows 2000/XP/Vista or Mac OS 9.2.2 and Mac OS X 10.2 or later consumption of the monitor varies consumption of the monitor varies (3) EIZO USB cable (MD-C93) with connected devices even in the with connected devices even in the power saving mode. -
Page 31: Chapter Troubleshooting
Chapter Troubleshooting If a problem still remains after applying the suggested remedies, contact your local dealer. • No-picture problems → See No.1 - No.2. • Imaging problems (digital input) → See No.3 - No.8. • Imaging problems (analog input) → See No.3 - No.12. •... - Page 32 Problems Possible cause and remedy . Afterimages appear. • Use a screen saver or off timer function for a long-time image display. • Afterimages are particular to LCD monitors. Avoid displaying the same image for a long time. 6. Green/red/blue/white dots or defective dots remain • This is due to LCD panel characteristics and is not a on the screen.
- Page 33 Problems Possible cause and remedy 17. The monitor connected with the USB cable is not • Check whether the USB cable is connected correctly. detected. / USB devices connected to the monitor (see page does not work. • Change the USB port to another one. If the PC or peripheral devices works correctly by changing the USB port, contact your local dealer. (Refer to the manual of the PC for details.) •...
-
Page 34: Chapter Reference
The stand can be removed and replaced with an arm (or another stand) to be Attention • When attaching an arm or stand, attached to the monitor. Use an arm or stand of EIZO option. follow the instructions of their user’s manual. -
Page 35: Folding The Ez-Up Stand
- Folding the EZ-UP stand Perform the following procedures to fold the stand when re-packing a monitor with an EZ-UP stand. Remove the cable holder. Lower the monitor screen position until the hinge of the stand touches the stand base, and attach the lock metal fitting. Adjust the monitor angle so as the monitor screen not to touch the stand base. Lock metal fitting Hinge Stand Base Fall the monitor screen backward with keeping slide-up the “Unlock” knob. -
Page 36: Specifications
5-3 Specifications SW LCD Panel 22.0-inch (560 mm) TFT color LCD with anti-glare Viewing angle: Horizontal 178°, Vertical 178° (CR:10 or more) Dot Pitch 0.282 mm Horizontal Scan Frequency Analog: 31-82 kHz Digital: 31-65 kHz Vertical Scan Frequency Analog: 55-76 Hz (Non-interlace) (1680 ×... - Page 37 Mass Main unit (including Approx. 9.6 kg (21.2 lbs.) Height adjustable stand) Main unit (including Approx. 7.6 kg (16.8 lbs.) Tilt stand) Main unit (including EZ- Approx. 11.4 kg (25.1 Ibs.) UP stand) Main unit (without stand) Approx. 6.6 kg (14.6 lbs.) Movable range Height adjustable stand Tilt: 40°...
- Page 38 Analog Input Signal (Sync) Separate, TTL, positive/ negative Composite, TTL, positive/ negative Analog, Positive (0.7Vp-p/75Ω) Analog Input Signal (Video) Digital Signal Transmission System TMDS (Single Link) Video Signal Memory Analog signal: 45 (preset: 16) Digital signal: 10 Speaker output: 0.5W + 0.5W (8Ω, THD: 3% or less) Audio Output Headphone output: 2mW + 2mW Input impedance : 48 kΩ...
- Page 39 Vertical Scan Frequency Analog: 55-76 Hz (Non-interlace) (1920 × 1200: 55-61 Hz) Digital: 59-61 Hz (Non-interlace) (VGA TEXT: 69-71 Hz) Resolution 1920 dots × 1200 lines Max. Dot Clock Analog: 202.5 MHz Digital: 162 MHz Max. Display Color Approx. 16.77 million colors: Applicable to 8 bit (1064.33 million colors/10bit LUT) Display Area (H ×...
- Page 40 Environmental Temperature Operating temperature: 5 °C - 35 °C (41 °F - 95 °F) Conditions Storage temperature: -20 °C - 60 °C (-4 °F - 140 °F) Humidity Operating humidity: 30% - 80% R.H. (no condensation) Storage humidity: 30% - 80% R.H. (no condensation) Pressure Operating: 700 to 1,060 hPa Storage: 200 to 1,060 hPa...
-
Page 41: Chapter 5 Reference
Outside Dimensions SW/SW (Height adjustable stand) 481.5(19) unit : mm (inch) 168(6.6) SWIVEL 240.5(9.5) 325(12.8) 264.5(10.4) 511(20.1) 17.6(0.69) 475.8(18.7) 17.6(0.69) 205.5(8.1) 100(3.9) 205.5(8.1) PIVOT (0.79) 208.5(8.2) SW/SW (Tilt stand) unit : mm (inch) 481.5(19) 164(6.5) 511(20.1) 228(9) 17.6 475.8(18.8) 17.6(0.69) 178(7) (0.69) 205.5(8.1) 100(3.9) 205.5(8.1) 27(1.06) 205(8.1) Chapter 5 Reference... - Page 42 SW/SW (EZ-UP stand) 481.5(1.9) unit : mm (inch) 129.3(5.1) SWIVEL (220) 511(20.1) (208.5) 17.6(0.69) 475.8(18.7) 17.6(0.69) 205.5(8.1) 100(3.9) 205.5(8.1) PIVOT 64.3 27.5 φ272(10.7) (2.53) (1.08) 307.5(12.1) 279.9(11) SW (Height adjustable stand) 532(20.9) unit : mm (inch) 168(6.6) SWIVEL 240.5(9.5) 325(12.8) 287.5(11.3) 566(22.3) 22.8(0.9) 520.4(20.5) 22.8(0.9) 233(9.2) 100(3.9) 233(9.2)
- Page 43 SW (EZ-UP stand) 532(20.9) unit : mm (inch) 129.3(5.1) SWIVEL 566(22.3) 22.8(0.9) 22.8(0.9) 520.4(20.5) 233(9.2) 100(3.9) 233(9.2) PIVOT 64.3(2.53) 27.7(1.09) Ø272(10.7) 279.9(11) 307.6(12.1) Connector Pin Assignment • DVI-D connector Pin No. Signal Pin No. Signal Pin No. Signal T.M.D.S. Data 2- T.M.D.S. Data1- T.M.D.S. Data0- T.M.D.S. Data 2+ T.M.D.S.
- Page 44 Serial data Ground Cable ground Accessories List Cleaning Kit EIZO ScreenCleaner Speaker Unit i•Sound L3* * May not allowed to attach the option speaker depending on the stand type. For the latest information about the accessories, refer to our web site.
-
Page 45: Glossary
- Glossary Clock The analog input monitor needs to reproduce a clock of the same frequency as the dot clock of the graphics system in use, when the analog input signal is converted to a digital signal for image display. This is called clock adjustment. - Page 46 Resolution The LCD panel consists of numerous pixels of specified size, which are illuminated to form images. This monitor consists of 1680 (S2232W) / 1920 (S2242W/S2432W) horizontal pixels and 1050 (S2232W) / 1200 (S2242W/ S2432W) vertical pixels. At a resolution of 1680× 1050 (S2232W) / 1920 × 1200 (S2242W/S2432W), all pixels are illuminated as a full screen (1:1).
-
Page 47: Preset Timing
- Preset Timing The following table shows factory preset video timing (for analog signal only). Attention • Display position may be deviated depending on the PC connected, Frequency which may require screen adjustment Mode Dot clock Horizontal: kHz Polarity using Adjustment menu. Vertical: Hz •... - Page 48 Congratulations! The display you have just purchased carries the TCO’03 Displays label. This means that your display is designed, manufactured and tested according to some of the strictest quality and environmental requirements in the world. This makes for a high performance product, designed with the user in focus that also minimizes the Impact on our natural environment.
-
Page 49: Fcc Declaration Of Conformity
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Note Use the attached specified cable below or EIZO signal cable with this monitor so as to keep interference within the limits of a Class B digital device. - AC Cord... -
Page 50: Hinweise Zur Auswahl Des Richtigen Schwenkarms Für Ihren Monitor
Hinweise zur Auswahl des richtigen Schwenkarms für Ihren Monitor Dieser Monitor ist für Bildschirmarbeitsplätze vorgesehen. Wenn nicht der zum Standardzubehör gehörige Schwenkarm verwendet wird, muss statt dessen ein geeigneter anderer Schwenkarm installiert werden. Bei der Auswahl des Schwenkarms sind die nachstehenden Hinweise zu berücksichtigen: Der Standfuß...
