Instruction book
Seed drill
EuroDrill and EuroDrill-S
Safety is our concern!
Art.Nr. 175 1246
K-2/04.98
LEMKEN GmbH & Co. KG
Weseler Straße 5, D-46519 Alpen / Postfach 11 60, D-46515 Alpen
Telefon (0 28 02) 81-0, Telefax (0 28 02) 81-220
eMail: lemken@lemken.com, Internet: http://www.lemken.com

Advertisement

Table of Contents
loading

Summary of Contents for LEMKEN EuroDrill

  • Page 1 EuroDrill and EuroDrill-S Safety is our concern! Art.Nr. 175 1246 K-2/04.98 LEMKEN GmbH & Co. KG Weseler Straße 5, D-46519 Alpen / Postfach 11 60, D-46515 Alpen Telefon (0 28 02) 81-0, Telefax (0 28 02) 81-220 eMail: lemken@lemken.com, Internet: http://www.lemken.com...
  • Page 3: Table Of Contents

    Under „defined use“ the manufacturer’s prescribed operation-, maintenance- and repair conditions are to be adhered to! • The seed drill EURODRILL may only be operated, maintained and repaired by such persons who have been made acquainted with it and who have been advised about the dangers! •...
  • Page 4 5.3.2 Slides......................... 12 5.3.3 Bottom flaps ......................12 5.3.4 Combi-Seed Wheel Vario-Plus................13 5.3.5 Switching on and off of the seed wheel halves............. 13 5.3.6 Adjustment of the seed rate..................14 5.4 Calibration test ....................14 5.5 Calculation slide....................16 5.6 Seeding control ....................17 5.7 Emptying the hopper ..................17 6 COULTERS ........................18 6.1 Standard coulters....................18...
  • Page 5 19 DISCHARGE WEDGES ................... 27 20 REMOTE CONTROL FOR THE ADJUSTMENT OF THE SEED QUANTITY ..28 21 DOUBLE SIDED DRIVE................... 28 22 RAPE SEPARATION PLATE .................. 29 23 WHEEL SCRAPERS....................29 24 LOWER LINKS ......................29 24.1.1 Drawbar Cat. I ......................29 24.1.2 Drawbar Cat.
  • Page 6: Safety Instructions

    1 SAFETY INSTRUCTIONS • Before use, always check both the machine and the tractor for road- worthiness and operational safety. • As well as the notes in these instructions the operator is advised to comply with the generally applicable safety at work regulations and those relating to use on the public highway.
  • Page 7 • Regularly check the hydraulic pipes and replace them in the event of damage or signs of ageing. The replacement pipes must comply with the technical specification as laid down by Lemken. • Hydraulic oil escaping at high pressure can penetrate the skin and cause serious injury! •...
  • Page 8: Warning Stickers

    2 WARNING STICKERS WARNING: LOCK HYDRAULIC DEVICE BEFORE GOING HAZARDOUS AREA! WARNING: DO NOT RIDE WITH ON THE PLATFORM OF THE IMPLEMENT! WARNING: DANGER - STAY CLEAR OF ROTATING MACHINE PARTS! WARNING: PINCH POINT! WARNING: RIDE PLATFORM LADDER! ATTENTION: SUSPEND IMPLEMENT HERE!
  • Page 9: Preparation Of The Tractor

    3.6 Hydraulic equipment The following spool valves must be available at the tractor for the mounted seed drill EURODRILL: Required spool valves single acting double acting...
  • Page 10: Attaching And Detaching Of The Seed Drill

    As standard the EuroDrill is equipped with the drawbar Cat. II. The top link pin can be used alternatively for category I or II.
  • Page 11: Parking The Implement

    4.3 Parking the implement The EuroDrill will be supplied with lifted coul- ters and without fitted harrow for dispatch reasons. For this reason two outer coulters are fitted as stands. With the seed drill of 4,00 m and 4,50 m an additional stand is fitted.
  • Page 12 The adjustment information for the setting of the seed drill and the adjustment of the first calibration test can be taken from the above table. By means of the Lemken calculation slide the required gear box adjustment can be cal- culated after the first calibration procedure (picture LRS-01 and LRS-02).
  • Page 13: Filling The Hopper

    5.2 Filling the hopper Before filling the bottom flaps must be ad- justed! The hopper may only be filled when the seed drill is fitted to the tractor or fitted to the tractor with a soil cultivation implement. No foreign parts (like a packing list) may be inside the hopper.
  • Page 14: Slides

    The agitator rods are fitted to the agitator shaft by means of clamps. (Picture DKA-34). 5.3.2 Slides By means of adjusting the slides (AS) in four steps the seed flow to the seed wheel hous- ings can be regulated. 0 = Position "CLOSED“ for closing the re- quired row.
  • Page 15: Combi-Seed Wheel Vario-Plus

    5.3.4 Combi-Seed Wheel Vario-Plus The Combi-Seed Wheel VARIO-PLUS can be adjusted in three different adjustment positions. With these seed wheels all usual kinds of seed can be seeded. Full seed wheel (1/1): With this adjustment both halves of the seed wheel are switched on. This ad- justment will be chosen for most types of crops and large-grained seed.
  • Page 16: Adjustment Of The Seed Rate

    If the scale value is doubled for example, the seed quantity will be doubled, too. By means of the Lemken calculation slide the required gear box adjustment can be calculated eas- ily after the first calibration test. Before starting to seed it must always be checked whether the adjusted seed rate is sufficient.
  • Page 17 Weighed out quantity of seed for 1/10 ha x 10 = quantity of seed per hectare With deviations from the required quantity of seed, adjust the gear box according to the Lemken calculation slide. (Picture LRS-01 and LRS-02) During calibration a clicking noise may occur in the gear box due to the overrun clutch.
  • Page 18: Calculation Slide

    5.5 Calculation slide The Lemken calculation slide replaces the seed table, which has been delivered with each seed drill. The calculation slide shows the following functions and adjustment in- structions: 1. Adjustment data according to the seed for the bottom flaps, the seed wheel and the slide as well as an additional adjustment recommendation of the gear box, and that for the first calibration test.
  • Page 19: Seeding Control

    (below or above the re- quired seed quantity 202 kg/ha) and adjust the gear box concerned = 75. It must be ensured that the adjustment- and reading data of the Lemken calculation slide are always on the same scale line! A separate operation instruction in English and French language is stated on the inside page of the calculation slide.
  • Page 20: Coulters

    6 COULTERS The Lemken seed drill EuroDrill is available with standard coulters (SI) or disc coulters (SB). It must be ensured, that the seed drill is always lowered when in a forward motion, in order to prevent clogging of the shares.
  • Page 21: Track Scraper Outer Coulter Sb

    6.1.2 Track scraper outer coulter SB The EuroDrill can be equipped with this coul- ter subsequently, if it is not fitted as standard. The special advantage of this coulter is that besides an exact working depth no blocking is ensured.
  • Page 22: Transport Locking Device Of The Coulters

    The screw position and the adjusted pres- sure can be read on the scale. The central coulter pressure adjustment is standard equipment of the EuroDrill. 8.3 Hydraulic pressure adjustment Instead of the screw (SP) of the central pressure adjustment an hydraulic ram (hydraulic pressure adjustment) is available as an option.
  • Page 23: Harrows

    9 HARROWS 9.1 General For covering the seed with soil the following harrows can be used, depending on the soil conditions. 9.2 Split harrows With a working width up to 3 m this harrow consists of 2 swinging suspended harrow sections.
  • Page 24: Adjustment Instructions

    9.5 Adjustment instructions For fitment of the top- and lower links to the brackets (KO) several hole sizes are avail- able. The top- and lower links of the linkage can be fitted to the linkage in different posi- tions. Therefore the position of the harrow can be changed.
  • Page 25: Hydraulic Track Marker Operation In Connection With Pre-Germination Marker

    For the change of the track markers the hydraulic ram will be closed completely and after that opened again. The reverse mechanism controls the change of track markers. For the hydraulic operation a single acting tractor spool valve is required. In order to reduce the lifting speed an adjustable restrictor is provided at the screw connection of the hydraulic port.
  • Page 26: Tramlining Rhythm

    13 TRAMLINING RHYTHM A tramlining rhythm must be chosen. There are 2 possibilities. 13.1 Uneven rhythm The working width of the sprayer or fertiliser spreader may be 3, 5, 7 or 9 times greater than the seed drill width. Example: Sprayer Seed drill Tramline rhythm...
  • Page 27: Adjustment Of The Tramline Width

    14 ADJUSTMENT OF THE TRAMLINE WIDTH The tramline width must correspond to the track width of the tractor which will be used with a sprayer or fertiliser spreader. From the centre of the seed drill the dimension of a half of the tramline width for exam- ple with a track of 1,50 m = 0,75 to the right and to the left is measured and then the two closest coulters must be chosen at the measured value.
  • Page 28: Conversion Of The Tramline To An Other Track Width

    15 CONVERSION OF THE TRAMLINE TO AN OTHER TRACK WIDTH − Choose the required seed wheels (SR) for the new track width. − Rotate the seeding shaft to view the groove (KN). − Make the gears on the intermediate shaft (VG) axially moveable by means of loosen- ing the clamps (SC).
  • Page 29: Fitting A Third Row

    16 FITTING A THIRD ROW The width of the track will be determined by the row distance and the number of closed seed wheels. If wider tracks are desired than can be reached with 2 rows, a third row can be fitted. −...
  • Page 30: Remote Control For The Adjustment Of The Seed Quantity

    − The position of the discharge wedges be- tween the seed housings are marked with a centre mark. − Bore a hole of 5 mm diameter in the marked position between the seeding housings and the rear wall of the hopper and debur it.
  • Page 31: Rape Separation Plate

    22 RAPE SEPARATION PLATE In order to ensure an ideal seeding with very little seed in the hopper, the hopper can be equipped with separation plates. The separation plate (RT) is fitted in the rear area of the hopper and must be detached when seeding wheat.
  • Page 32: Track Scrapers

    26 TRACK SCRAPERS They are fitted at the front of the implement frame in the area of the tractor wheels. Two tines for each wheel track. It must be ensured, that no tines are working directly in front of a seeding coulter and the working depth is not adjusted fundamentally deeper than the seeding depth.
  • Page 33: Sensors

    28 SENSORS The sensors for the tramline switch can be fitted in the area of the drawbar (Edrill-28), at the hydraulic ram of the track markers (Edrill-29), at the roller depth adjustment (Edrill- 30) of the power harrow Zirkon or rotary harrow Granit or at the lift linkage of the tractor. Each sensor (SE) must be adjusted by means of the nut (MU) so that the distance between sensor and screw (SC), the plate...
  • Page 34: Lighting Equipment, Transport On Public Roads

    29 LIGHTING EQUIPMENT, TRANSPORT ON PUBLIC ROADS When driving on public roads with this im- plement, fit warning boards. The EuroDrill is available with lighting equipment according to the GEKA fitting system. For transport the warning boards with lighting equipment must be fitted into the socket (SD).
  • Page 35: Drive Chains

    The wiring diagram is found on the inside of the junction box, which is fitted at the front of the hopper. 31 NOISE, AIRBORNE SOUND The noise level of the seed drills EURODRILL exceeds 70 dB (A) during work. Close the tractor cabin or use ear plug.
  • Page 36: Notes

    (approx. l) EuroDrill 250 EuroDrill 300 EuroDrill 300 EuroDrill 400 EuroDrill 400 EuroDrill 450 1087 EuroDrill-S 250 250 EuroDrill-S 300 300 EuroDrill-S 400 400 EuroDrill-S 450 450 1087 34 SPARE PARTS FOR THE ON-BOARD COMPUTER LH 1600 Part-No. Description Dimension...
