Door Opening - Sub-Zero 695 Planning Information

Planning Information
Built-In Model 695
O V E R L A Y P A N E L A P P L I C A T I O N – 9 0 ˚ D O O R O P E N I N G
90˚ DOOR OPENING
(TOP VIEW)
7
23 / "
8 (606) TO REAR
OF SUB-ZERO
OVERLAY PANEL
3/4" (19) THICK (NOMINAL)
*Approximate thickness of wrapped
stainless steel door.
Dimensions in parentheses are in
millimeters unless otherwise specified.
NOMINAL OVERALL
WIDTH OF SUB-ZERO
MAIN FRAME
HINGE
DOOR OPEN @ 90˚
SUB-ZERO UNIT
DOOR CLOSED
16
