- Page 1 ITS All-in-one Traffic Camera Configuration Manual Hikvision iDS-TCV9(5)07 Breve Manual (Radar trigger)
- Page 2 INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA OR DOCUMENTATION, IN CONNECTION WITH THE USE OF THIS PRODUCT, EVEN IF HIKVISION HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
- Page 3 SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION BEFORE USING THIS PRODUCT IN ORDER TO ENSURE THAT YOUR USE CONFORMS THE APPLICABLE LAW. HIKVISION SHALL NOT BE LIABLE IN THE EVENT THAT THIS PRODUCT IS USED WITH ILLEGITIMATE PURPOSES.
-
Page 4: Table Of Contents
ITS All-in-one Traffic Camera Configuration Manual Contents CHAPTER 1 OVERVIEW ....................... 4 ..........................4 BJECTIVE ........................4 ARGET EADER ......................4 AFETY RECAUTIONS CHAPTER 2 DEVICE ACTIVATION ..................5 CHAPTER 3 CAMERA CONFIGURATION ................8 ............8 PGRADING ROGRAM AND ESTORING EFAULT ETTINGS... -
Page 5: Chapter 1 Overview
ITS All-in-one Traffic Camera Configuration Manual Chapter 1 Overview 1.1 Objective This manual is designed to provide standard engineering guidelines for the construction and configuration of the All-in-one Traffic Camera. 1.2 Target Reader This manual is written for implementation and maintenance personnel who will install and configure the All-in-one Traffic Camera. -
Page 6: Chapter 2 Device Activation
For the first use of the camera, you need to activate the device by setting an admin password. No operation is allowed before activation. You can activate the device via SADP. Steps: 1. Download SADP from the official website‘https://www.hikvision.com/en/’. 2. Run the software. SADP will automatically search all online devices in LAN. The results are displayed in sheet, with device type, IP address, security status, device serial No. - Page 7 ITS All-in-one Traffic Camera Configuration Manual Figure 2-2 Activate the Capture Camera 6. Check the activated camera to pop up the Modify Network Parameters window on the right. 7. Enter camera IP address, subnet mask and admin password. 8. Click Modify to finish IP settings. Figure 2-3 Modify Camera IP Address 9.
- Page 8 ITS All-in-one Traffic Camera Configuration Manual Figure 2-4 Modify Computer IP Address 10. Using Chrome or IE browser to login the camera. Figure 2-5 Login...
-
Page 9: Chapter 3 Camera Configuration
ITS All-in-one Traffic Camera Configuration Manual Chapter 3 Camera Configuration 3.1 Upgrading Program and Restoring Default Settings .Steps: Go to Configuration > Capture Maintenance. Steps: 1. Choose Firmware. 2. Click Upgrade. 3. Restore the camera. 3.2 Modifying Time Zone Steps: 1. -
Page 10: Set License Plate Recognition Parameters
ITS All-in-one Traffic Camera Configuration Manual 3. Click Save. Set License Plate Recognition Parameters Go to Configuration → Capture → Capture Parameters → License Parameters. Set Country/Region according to the actual needs. Select License Plate Recognition. – Select Forward when license plates of vehicles from the approaching direction need to be recognized. -
Page 11: Configuring Application Mode Parameter
ITS All-in-one Traffic Camera Configuration Manual 3.5 Configuring Application Mode Parameter Go to Configuration > Capture > Application Mode. Steps: 1. Click RS-485 Radar. 2. Scroll down to save. 3. Reboot the camera. 4. Total Lanes The sum of the linked lane(s) under the current application mode. - Page 12 ITS All-in-one Traffic Camera Configuration Manual Select the connected radar type and choose RS-485 port2, because the radar’s RS485 wire was connected with port2. 5. Click “Draw Lane line”. 6. Click Save.
-
Page 13: Configuring Flash Light Parameters
ITS All-in-one Traffic Camera Configuration Manual 3.6 Configuring Flash Light Parameters 3.7 Configuring Image Parameters Steps: 1. Keep parameters as default. If necessary, you can adjust Shutter and Gain. 2. Shutter should be in the range of 800~4000. Normally set it as default 2000. 3. -
Page 14: Chapter 4 Radar Detection
ITS All-in-one Traffic Camera Configuration Manual Chapter 4 Radar Detection Before You Start Select the application mode as RS-485 Radar, and select Radar Type as Multi-Lane Radar. Steps Note The function varies with different models. The actual device prevails. 1. Click Radar. 2. - Page 15 ITS All-in-one Traffic Camera Configuration Manual status can be restored to normal. 3. Check Debug Mode to set the parameters. 1) Set construction parameters. Construction Height Set the construction height of the radar according to construction at the actual scene. Angle Deviation Set the angle compensation according to the target moving track detected by the radar.
- Page 16 ITS All-in-one Traffic Camera Configuration Manual Track Correction Track Correction 0° 12° Track Correction 12° Horizontal Deviation The Horizontal Deviation is to guarantee that the radar track will not be too left or too right deviated from the lane lines. Set the deviation between the radar construction position and the horizontal central position.
- Page 17 ITS All-in-one Traffic Camera Configuration Manual Trigger Vehicle Tail Capture is triggered by the vehicle tail. The vehicles from the leaving direction will be detected. Trigger Vehicle Head and Tail Capture can be triggered by the vehicle head or tail. The vehicles from both the approaching and leaving directions will be detected.
