WiebeTech FSDK User Manual

Forensic SATADock™

Forensic Device User Advisory

We recommend that you perform a final check on this product.
Prior to first use, please verify that the write-blocking function of this product is working properly. This is
easily done: attach a known good formatted drive, and verify that the drive mounts properly on your
computer. Use a drive that has data on it that you are willing to overwrite. Transfer files to the drive. The
files will appear to transfer to the drive. Thereafter, unmount the drive and remount the drive. The files
that you wrote to the drive should not appear after the drive is remounted. If they do appear, there is a
problem with your Forensic Device, and you should contact our support department for further
instructions.

Installation Instructions

1. Check the accessories with your SATADock. Please contact WiebeTech if any items are missing or damaged.
The box should contain:
SATADock
AC adapter & power cord
FireWire 800 cable
SATA cable
Metal bottom plate
Hard drive screws
Rubber bumpers
Manual and Warranty information
2. Attach bottom plate to your 3.5" hard drive. This step is optional but recommended. The
purpose of the bottom plate is to provide protection to your drive electronics. Attach the bottom plate
to your drive using the four screws that are supplied. Attach a rubber bumper to each corner. Extra
bottom plates are available from WiebeTech.
F o r e n s i c S AT A D o c k U s e r M a n u a l
USER'S MANUAL
Revised May 2, 2007

Features

• Connects any 3.5" or 2.5" SATA drive through FireWire 800
(400 compatible) or USB2.
• Write blocking preserves the integrity of evidentiary drives.
• Fully plug & playable, working with almost any Mac or PC
without requiring drivers.
• Power switch allows drives to be powered off when not in use.
• Two LEDs show the status of both power and drive access.
• Anodized aluminum case for rugged durability.
Small size for easy portability. Carry it anywhere!
•
1
1
1
1
1
4
4
(on CD)
- 1 -
