WiebeTech TCS1-1 Quick Start Manual

Quick Start Guide

Tera Card TCS1-1 and TCS2-0 SATA hosts
TCS1-1

Package contents

•
PCI card
•
Extra bracket for use with low profile computer cases.
•
CD containing user's manual, warranty information, and drivers
Installatio n
1. Power down the computer syst
2. Open the computer case.
3. Insert the PCI board into an available 32-bit or 64-bit PCI or PCI-X slot. Do not force it,
but it will take firm pressure to insert the card. Make sure the card is ful
slot. Note: the card is not compatible wi
4. Secure the card in place w
5. Power up the computer.
6. Follow the instructions for your computer type to install firmware/drivers.
W indows driver Installation
1. Browse to the folder "TCS1-1, TCS2-0 Windows
2. Follow the instructions in the "readme.txt" file.
In stalling firmware for Mac Usage
Browse to the folder "TCS1-
"F lashrom.command" file.
When you launch the file, a terminal window will open and prompt you to "enter C to con
Press "C" on your keyboard and hit enter. The terminal window will now look like this:

Features

• 32 bit, 33/66MHz fully compliant PCI host interface
• Two brackets to support low profile PCI and regular
size PCI in one card
• LBA supports smaller drives as well as drives larger
than 137GB
• Supports Spread Spectrum in receiver
• Supports two independent SATA channels
• Compliant with PCI Specification, revision 2.2
• Operating Systems: Mac OS X, Windows XP
em. Unplug the power cable.
ith a screw.
1, TCS2-0 Mac Firmware" on the CD. Open the
th PCI Express (PCI-e) slots.
Drivers" on the CD.
ly seated in the
tinue".
