PRE INSTALLATION NOTES The deadbolt included is preconfigured to fit a standard door frame. Note your 6 digit programming code located on a sticker on inside of your lock (alarm assembly) before you begin installation. This may be needed for panel pairing if this unit was not purchased as a part of your primary system order.
REQUIRED TOOLS Phillips Screwdriver (Included in your package) DO NOT use a power drill! A manual or electric screwdriver is safe, but a power drill may damage the lock. Additional Tools You May Need: • Tape Measure • Flathead Screwdriver •...
Page 6
When the door is closed, there is space for the deadbolt to extend 1” into the frame when locked. If you could not check every box in the checklist, you will need to adjust your door and/or frame. Please visit answers.schlage.com for more information.
(standard dimensions). If your door dimensions do not match, you will need to change your door preparation. If your door is thicker than 1 ¾”, you will need a thick door kit. Please call Schlage Customer Service at 1-888-805-9837. Mark your crossbore and backset measurements on the next page.
STEP 3 INSTALL BOLT AND STRIKE Adjust bolt length if necessary. Note: the bolt is preconfigured to fit the standard door dimensions mentioned in STEP 2. If your door matched the measurements in STEP 2, you do not need to adjust the length.
Page 9
3b: Change the faceplate if necessary. Note: The faceplate is currently preconfigured to fit the standard door frame. If your door matches the measurements in STEP 2, you can move on to step 3c.
Page 10
3c: Install the bolt into the door. IMPORTANT! Retract the bolt before continuing to step 3c! Choose the picture below that matches your door...
Page 11
3d: Install the strike into the frame. Note: This step is only if you did not complete the Figure A: Mortise install in step 3c. Install all of the parts shown below for maximum security. The reinforcement screws may not fit on doors with sidelights.
STEP 4 INSTALL THE TOUCHSCREEN ASSEMBLY Install the Touchscreen on the outside of the door. Note: if you have a crossbore (see step 2) that is slightly less than 2 1/8” (54 mm), the lock may not install smoothly. You can then remove the spacer to improve fitment. Always remove the space for a 1 ½”...
Page 13
4b: Install the Support Plate on the inside of the door. Note: Make sure that once tightened, the support plate can not move left or right by hand. Be mindful not to over tighten any screws. Make sure the Touchscreen and Support Plate are straight on the door before tightening the screws.
Page 14
STEP 5 INSTALL THE INSIDE ASSEMBLY Remove the battery cover from the Inside Assembly. Note: Avoid contact with the circuit board due to electrostatic discharge!
Page 15
5b: Connect the cable to the Inside Assembly. Locate the screws in step 5d before beginning this step so they will be handy when you need them. 5c: Install the Inside Assembly. Align the tab with the notch as shown. Route the cable into the channel.
Page 16
5d: Secure the Inside Assembly to the Support Plate. Note: Do not rotate the thumbturn at this time. It may not rotate easily. Setup will be performed after the installation is complete.
Page 17
4. Carefully replace the battery tray, with the batteries facing the door. Do not connect the battery connector at this time. 5. Press and hold the Schlage Button. 6. While holding the Schlage Button, reconnect the batteries. 7. Release the Schlage Button.
Page 18
6b: Install the battery cover Once the battery cover has been installed, door installation is complete. To complete pairing with your Frontpoint system, refer to your Smart Lock Code Guide. 877-602-5276...
