Schlage BE365 Programming/Operating Manual

Door lock
Hide thumbs Also See for BE365:
Table of Contents

Advertisement

Quick Links

See also: Owner's Manual , User Manual
P515-549
BE365
FE575
FE595
Preset Codes
Programming Code: 123456
User Code A: 4321
User Code B: 5678
Example
Example
Preset User Codes
BE365, FE575, FE595
Programming/Operating Guide

Table of Contents

BE365 Features .......................................................2
Lock Operation ............................................2
Changing the Battery ...................................3
FE575 Features .......................................................4
Lock Operation ............................................4
Changing the Battery ...................................5
FE595 Features .......................................................6
Lock Operation ............................................6
Changing the Battery ...................................7
Programming for All Models ....................................8
Keeping Your Lock Secure .....................................10
Key Override ..........................................................10
Troubleshooting Guide ...........................................11
Emergency Lock Override .....................................12
S/N: 1-00000000
Model: BE365
Preset Programming Code
Serial Number
Lock Series
Place Label Here

Advertisement

Table of Contents
loading

Related Manuals for Schlage BE365

Summary of Contents for Schlage BE365

  • Page 1: Table Of Contents

    BE365, FE575, FE595 Programming/Operating Guide P515-549 Table of Contents BE365 Features ............2 Lock Operation ..........2 Changing the Battery ........3 FE575 Features ............4 BE365 Lock Operation ..........4 Changing the Battery ........5 FE595 Features ............6 Lock Operation ..........6 Changing the Battery ........7 Programming for All Models ........8...

  • Page 2: Be365 Features

    E. Inside Thumbturn 2. Use to program the lock. (See page 8.) Extends and retracts the deadbolt from the inside. BE365 Lock Operation To Retract the Deadbolt To Extend the Deadbolt a. Enter a valid four-digit user code. a. Push button.

  • Page 3: Changing The Battery

    BE365 Lock Operation Continued Locked - Deadbolt Extended Unlocked - Deadbolt Retracted Locked - Unlocked - User code No user code Deadbolt required required for entry for entry BE365 Changing the Battery For low battery indications, see page 11. NOTE: Replace with premium 9V alkaline battery.

  • Page 4: Fe575 Features

    FE575 Features Button B. Keypad C. Key Override D. Outside Knob/Lever E. Inside Knob/Lever Button C. Key Override (See page 10.) 1. Press to turn on backlight. 2. Press to clear an incorrect code entry. D. Outside Knob/Lever B. Keypad Always rotates.

  • Page 5: Changing The Battery

    FE575 Changing the Battery For low battery indications, see page 11. NOTE: Replace with premium 9V alkaline battery. Reverse steps to assemble lock.

  • Page 6: Fe595 Features

    FE595 Features Button B. Keypad C. Key Override D. Thumbturn E. Outside Knob/Lever F. Inside Knob/Lever Button D. Thumbturn Switches between locked and unlocked. 1. Press to turn on backlight. 2. Press to clear an incorrect code entry. (See below.) B.

  • Page 7: Changing The Battery

    FE595 Lock Operation Continued To Unlock the Lock (While thumbturn is in locked position) a. Enter a valid four-digit user code. (See note.) b. The button will fl ash green c. Rotate outside knob/lever within fi ve seconds to open door. d.

  • Page 8: Keypad Codes

    Example Example • Won't program lock Schlage Button (on front of lock) • Lights orange while in programming mode. • Flashes green when programming is successful. • Lights red when there is an error. Retry steps or see troubleshooting guide on page 11.
  • Page 9 IMPORTANT: Lock will be reset to the preset programming and user codes. All existing user codes and current programming code will be erased. 1. Disconnect the battery. (For FE575, see page 3. For FE595, see page 5. For BE365, see page 7.) 2. Press and release 3. Reconnect the battery and wait until is no longer lit.

  • Page 10: Keeping Your Lock Secure

    Rotate knob/lever. back to relock. remove key. 270° 270° Key cannot be removed in this position. BE365 Only NOTE: Key will both extend and retract deadbolt. Rotate key and Push key into Insert key. Rotate key 90°. thumbturn 90°. thumbturn.

  • Page 11: Troubleshooting Guide

    None seconds, then replace battery. numbers are pressed. For FE575, see page 3. For FE595, see page 5. For BE365, see page 7. Battery is low and should be replaced. There is a delay before unlock High/Low, Red then For FE575, see page 3.

  • Page 12: Emergency Lock Override

    Emergency Lock Override If the outside thumbturn does not freely rotate or the lock is malfunctioning, you can enable the emergency override feature. When emergency override is engaged, a key must be used to extend/retract the deadbolt. a. Remove screws and thumbturn assembly. b.
