R E M O T E D E V I C E M A N A G E M E N T ( R D M )
NOTE: In order for RDM to work properly, RDM enabled equipment must be used through-
out the entire system, including DMX data splitters and wireless systems.
Remote Device Management (RDM) is a protocol that sits on top of the DMX512 data stan-
dard for lighting, and allows the DMX systems of the fixtures to be modified and monitored
remotely. This protocol is ideal for instances in which a unit is installed in a location that is
not easily accessible.
With RDM, the DMX512 system becomes bi-directional, allowing a compatible RDM enabled
controller to send out a signal to devices on the wire, as well as allowing the fixture to re-
spond (known as a GET command). The controller can then use its SET command to modify
settings that would typically have to be changed or viewed directly via the unit's display
screen, including the DMX Address, DMX Channel Mode, and Temperature Sensors.
FIXTURE RDM INFORMATION:
Device ID
0043
Please be aware that not all RDM devices support all RDM features, and therefore it is im-
portant to check beforehand to ensure that the equipment that you are considering includes
all of the features that you require.
The following parameters are accessible in RDM on this device:
[0x0200] Sensor Definition
[0x0201] Sensor Value
[0x0080] Device Model Description
[0x0081] Manufacturer Label
[0x0082] Device Label
[0x00E0] DMX Personality
[0x00E1] DMX Personality Description [0x0122] Default Slot Value
[0x0400] Device Hours
[0x0015] Comms Status
[0x0031] Status ID Description
[0x0032] Clear Status ID
[0x0402] Lamp Strikes
[0x0404] Lamp Mode
[0x0405] Device Power Cycles
[0x0600] Pan Invert
[0x0601] Tilt Invert
Device Model ID
43
18
RDM Code
Personality ID
001: Standard
002: Extended
003: RGB
0x22A6
004: RGB Extended
005: CMY
006: CMY Extended
[0x0602] Pan Tilt Swap
[0x0500] Display Invert
[0x0501] Display Level
[0x0603] Realtime Clock
[0x1010] Power State
[0x1031] Preset Playback
[0x00B0] Language
[0x00A0] Language Capabilities
[0x00C2] Boot Software Version Label
[0x00C1] Boot Software Version ID
[0x0070] Product Detail ID List
[0x0030] Status Messages
[0x1001] Reset Device
[0x0014] Undefined PID
