Seagate Lyve Mobile Link Quick Start Manual page 12

Rackmount Receiver
A Connect an Ethernet cable to a management port on Rackmount Receiver.
B Connect the other end of the cable to STORAGE MGMT A or B on Link. Make sure to select the
STORAGE MGMT port controlling data to the STORAGE CONNECTION port selected in step 1.
Management Port
STORAGE MGMT A
STORAGE MGMT B
Slot A
ACT
12
Data Ports
STORAGE CONNECTION A
STORAGE CONNECTION B
Slot B
ACT
A
IGN DP DP
APPLIANCCE
MGMT
LAN 1
10GbE
STORAGE STORAGE
MGMT A MGMT B
USB 3.2
STORAGE CONNECTIONS
A B C D
LAN 2 LAN 3
100GbE 100GbE
B
