QLL23 INSTRUCTION MANUAL
We'll Make It Stress-Free
If you have any questions along the way, just give us a call.
1-800-359-5520. We're ready to help!

Advertisement

loading
Need help?

Need help?

Do you have a question about the QLL23 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Secura QLL23

Summary of Contents for Secura QLL23

  • Page 1 QLL23 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-800-359-5520. We’re ready to help!
  • Page 2 Does your TV weigh more than 100 lbs. (45.3 kg) including accessories? No — Perfect! 100 lbs. Yes — This mount is NOT compatible. Visit secura-av.com or call 1-800-359-5520 (UK: 0800-056-2853) to fi nd a compatible mount. (45.3 kg) What is...
  • Page 3 Dimensions TV INTERFACE 23.62in [600mm] 7.87in [200mm] 16.73in [425.05mm] WALL PLATE 5.00in [127mm] 27.27in [692.7mm] 17.31in [439.74mm] 25.31in [642.94mm] 27.27in [692.7mm] 4.73in 7.00in [120] [177.80mm] SIDE VIEW - RETRACTED FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED 16.69in [423.95mm] 1.21in [30.69mm]...

  • Page 4: Parts And Hardware

    Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer; contact Customer Service. Never use damaged parts! NOTE: Not all hardware included will be used.
  • Page 5 Parts and Hardware for STEP 2 Lag Bolts 5/16 x 2¾ in. Wall Plate Lag Bolt Washers For concrete installations ONLY CAUTION : Do not use in drywall or wood Concrete Anchors Fischer UX 10 x 60R...

  • Page 6: Step 1 Attach Brackets To Tv

    STEP 1 Attach Brackets to TV Standard configurations are shown. For special applications, or if you 1.1 Select TV Screw Diameter 1.2 Select TV Screw Length are uncertain about your hardware selection, Hand thread screws into the threaded inserts If your TV has a flat back, AND you want your TV closer to contact Customer Service on the back of your TV to determine which the wall, use the shorter screws (a).
  • Page 7 1.3 Attach TV Brackets Ensure that your brackets are level and centered as much as possible on the back of the TV. Install using the screw/washer/spacer combination (a) or (b) you selected for your TV. CAUTION: Avoid potential personal injuries and property damage! DO NOT use power tools for this step.
  • Page 8 Attach Wall Plate STEP 2A Wood Stud Option CAUTION: Avoid potential personal injury or property damage! • Drywall covering the wall must not exceed 5/8 in. (16 mm) • Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm) •...
  • Page 9 Drill pilot holes using a 7/32 in. (5.5 mm) diameter drill bit. IMPORTANT: Be sure to drill into the center of the studs. IMPORTANT: Pilot holes must be drilled to a depth of 2 ¾ in. (70 mm). Install wall plate using four lag bolts and four washers .
  • Page 10 Attach Wall Plate Solid Concrete or Concrete Block Option STEP 2B CAUTION: Avoid potential personal injury or property damage! • Mount the wall plate directly onto the concrete surface • Minimum solid concrete thickness: 8 in. (203 mm) • Minimum concrete block size: 8 x 8 x 16 in. (203 x 203 x 406 mm) •...
  • Page 11 Insert four anchors CAUTION: Be sure the anchors are seated flush with the concrete surface. Install wall plate using four lag bolts and washers . Tighten the lag bolts only until they are pulled firmly against the wall plate. CAUTION: Improper use could reduce the holding power of the lag bolt.

  • Page 12: Step 3 Attach Tv To Wall Plate

    STEP 3 Attach TV to Wall Plate Install the TV / Bracket assembly by fitting the top hooks of the mounting brackets over the top edge of the wall plate Swing the mounting brackets down until the spring loaded locking tabs slip over and fully engage the bottom edge of the wall plate .
  • Page 13 Adjustments LATERAL SHIFT REMOVING THE TV Pull and hold release cords down while pulling the bottom of the TV Slowly slide the TV along wall plate out, and then lift the TV up and out away from the wall. HEAVY! You may need assistance with this step.
  • Page 14 Thank you for choosing Secura! Please take a moment to let us know how we did: Email us: info@secura-av.com Call us: 1-800-359-5520 UK: 0800 056 2853 Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations.
