- Page 1 QLF 214 INSTRUCTION MANUAL We’ll Make It Stress-Free If you have any questions along the way, just give us a call. 1-800-359-5520 We’re ready to help! Scan for easy install video san.us/1145...
- Page 2 Use with products heavier than the maximum weights Perfect – you may continue. indicated may result in collapse of the mount and its Yes? Visit secura-av.com or This mount is NOT compatible. call accessories, causing possible injury. 1-800-359-5520 (UK: 0800 056 2853) to fi nd a compatible mount.
- Page 3 Dimensions TV INTERFACE 100mm 3.94in 40mm 1.57in 400mm 15.75in 600mm 23.62in WALL PLATE TOP VIEW - EXTENDED SIDE VIEW - EXTENDED 25mm 80mm .98in 3.15in 5deg 15deg .35in 30deg 30deg 262mm 212mm 10.31in 8.35in ESTIMATED 55" TV 364mm 14.33in SIDE VIEW - RETRACTED FULLY ASSEMBLED MOUNT TOP VIEW - RETRACTED 3deg...
-
Page 4: Supplied Parts And Hardware
Supplied Parts and Hardware WARNING: This product contains small items that could be a choking hazard if swallowed. Before starting assembly, verify all parts are included and undamaged. If any parts are missing or damaged, do not return the damaged item to your dealer;... - Page 5 STEP 2 Parts and Hardware Lag Bolts 5/16 x 2¾ in. Wall Plate Assembly Washers (Lag Bolt) 5/16 in. For concrete installations ONLY CAUTION : Do not use in drywall or wood Concrete Anchors Fischer UX 10 x 60R Adjustments Hex Key 4 mm...
-
Page 6: Step 1 Attach Brackets To Tv
STEP 1 Attach Brackets to TV Standard configurations 1-1 Select TV Screw Diameter 1-2 Select TV Screw Length are shown. For special applications, or if you Hand thread screws into the threaded inserts If your TV has a flat back AND you want your TV closer to are uncertain about your on the back of your TV to determine which the wall, use the shorter screws (a). - Page 7 1-3 Attach TV Brackets Ensure that your brackets are level and centered on the back of the TV. Install using the TV screw/washer/spacer confi guration you selected for your TV. CAUTION: Avoid potential personal injuries and property damage! DO NOT use power tools for this step. Tighten the screws only enough to secure the TV bracket to the TV.
-
Page 8: Wood Stud Installation
Attach Wall Plate STEP 2A Wood Stud Installation CAUTION: Avoid potential personal injury or property damage! ● Drywall covering the wall, must not exceed 5/8 in. (16 mm) ● Minimum wood stud size: common 2 x 4 in. (51 x 102 mm) nominal 1½ x 3½ in. (38 x 89 mm) ●... - Page 9 Drill the two pilot holes using a 7/32 in. (5.5 mm) diameter drill bit. Be sure to drill into the center of the studs. IMPORTANT Pilot holes must be drilled to a depth of 2¾ in. (705 mm). Install wall plate assembly .
- Page 10 Attach Wall Plate Solid Concrete or Concrete Block Option STEP 2B CAUTION: Avoid potential personal injury or property damage! ● Mount the wall plate assembly directly onto the concrete surface. ● Minimum solid concrete thickness: 8 in. (203 mm) ● Minimum concrete block size: 8 x 8 x 16 in.
- Page 11 Insert three anchors CAUTION: Be sure the anchors are seated flush with the concrete surface. Install wall plate using three lag bolts and washers . Tighten the lag bolts only until they are pulled firmly against the wall plate. CAUTION: Improper use could reduce the holding power of the lag bolt.
-
Page 12: Step 3 Attach Tv To Wall Plate
STEP 3 Attach TV to Wall Plate HEAVY! You may need assistance with this step. CAUTION: Avoid potential personal injuries and property damage! Hang the TV / TV brackets onto the wall plate assembly TV brackets must be Allow the TV / TV brackets to rest against the arm assembly centered AND span the faceplate of the arm. - Page 13 Secure the TV brackets to the arm assembly by tightening locking screws IMPORTANT: You may need to back out the locking screws to allow the TV brackets to rest flat against the arm assembly plate CAUTION: Avoid potential personal injury or property damage! Locking screws must be tightened to secure the TV to the arm assembly...
- Page 14 TV Adjustments TILT ADJUSTMENT LEVEL ADJUSTMENT CAUTION: CAUTION: DO NOT REMOVE the tilt adjustment screws. DO NOT adjust the level for solid concrete ONLY loosen enough to make adjustments. or concrete block installations. For wood stud installations: To adjust the tilt level of your TV, using the 4 mm hex key , loosen Remove the TV before adjusting.
- Page 15 Features REMOVING THE TV Fully articulating arm, with Adjustments allow tilt control of TV To remove your TV from the arm assembly 3 pivot points, creates and restriction of TV movement , disconnect all cables and then reverse optimal viewing positions the procedures in STEP 3.
- Page 16 Thank you for choosing Secura! Please take a moment to let us know how we did: Email us: info@secura-av.com Call us: 1-800-359-5520 UK: 0800 056 2853 Milestone AV Technologies and its affi liated corporations and subsidiaries (collectively, “Milestone”), intend to make this manual accurate and complete. However, Milestone makes no claim that the information contained herein covers all details, conditions, or variations.
