Important information Before Getting Started

1) The microAeth Manager application for MacOS and Windows can be used to modify
all instrument settings but only some settings can be modified using the on-board user
interface on the front panel of the microAeth instrument.
2) Timebase:
The microAeth MA instruments can acquire data on timebase settings of 1, 5, 10, 30, 60,
or 300 seconds. The 1, 5 and 10 second timebases should only be used under special
circumstances where a decreased signal-to-noise ratio is acceptable. At this setting,
instrumental noise is larger and typically requires the highest flow rate and/or post-
processing. For stationary outdoor applications, we recommend longer timebases such as
the 300 second setting.
3) Flow Rate:
The MA series pump can operate at flow rate settings of 50, 75, 100, 125, 150 or 170 ml/
min. A higher flow rate can contribute to greater measurement sensitivity but will use more
filter tape and more power.
4) The lowest wavelength light source enabled will typically trigger the attenuation
(ATN) tape advance threshold. For example if 5 wavelengths are enabled, the UV channel
should always trigger the tape advance.
5) Measurement Wavelengths: What are you trying to measure? What wavelengths are
important for your measurements? More is not always better. Operating with the IR
channel only will increase tape life by at least 2.3x.
6) Tape advance ATN threshold: If DualSpot® is enabled, a higher ATN threshold can be
used as DualSpot will help correct for aerosol composition dependent loading effects.
7) DualSpot® vs SingleSpot™: A flow rate of 100 ml/min or greater is highly
recommended when using DualSpot® loading compensation. Using DualSpot® will
allow measurements at higher ATN loadings (longer sampling at each filter tape sampling
location) as the data are compensated in the BCc data column.
NOTE: Due to the flow split between Spot 1 and Spot 2 the measurement sensitivity in
DualSpot® mode will be lower than in SingleSpot™ mode for the same total flow rate that
is selected. When the DualSpot calculation and compensation is active (when ATN for
BC1 >= 3) the data will have more noise, this is expected behavior. Simple smoothing can
be applied to reduce the noise, or the smoothed columns in the data file can be used if
helpful.
8) Protect the instrument and the inlet and outlet ports from water and other
contaminates. Aethlabs can provide an inlet protection kit with a water/bug trap with rain
protection at the inlet.
9) Verify flow rates using on-board test flow menu and external flow calibration kit before
calibrating flows. The instruments are initially calibrated at sea level. Only calibrate the flow
system if there is an error in the measured flow when using the test flow menu. if sampling
is being done at a high elevation compared to sea level then a calibration may be required
to compensate for the change in altitude.
MA Series MA200, MA300, MA350 Quick Start Guide
microAeth
®
4
10) To get the best data from the microAeth MA Series instruments, we highly
recommend that the instrument warm up for approximately 30 minutes so that it can
equilibrate.
11) If you change sampling settings or download data (non-streaming data), you must
stop the instrument measurement before being allowed to make a change. Every time
the measurement starts into the sampling mode, the filter tape cartridge automatically
advances to a clean spot. Stopping and starting the instrument will therefore consume
more tape than just sampling without stopping the measurement intermittently.
Installation & Environmental Considerations
The microAeth instrument is specifically designed to be used in a wide range of
measurement scenarios. Each research deployment will require its own specific
considerations for protecting the instrument and ensuring the integrity of your data. The
included sample tubing assembly with threaded insert should be installed into the inlet of
the instrument. Obstruction of either the inlet or outlet port should be prevented as this
will affect the flow of air into the instrument.
In personal monitoring applications, the included lapel clip can assist in positioning the
sampling inlet near to the person's breathing zone, care must be taken to ensure the inlet,
or microCyclone inlet, are free from obstruction.
For outdoor deployments, protection of the instrument and the inlet and outlet ports
must be considered. An Inlet Protection Kit (WPK-20-25) should be used to help protect
the instrument and data from moderate water and bug intrusion and in-line condensation
through the sampling train.
Outdoor installation of MA series requires protection from rapid temperature changes and
moisture / precipitation. In addition to potentially having signal-to-noise implications on
your data, rapidly changing environmental conditions can harm your instrument without
proper protection. It is possible that an environmentally controlled enclosure could be
helpful and/or necessary. The instrument should be shielded from solar radiation to
reduce impact of rapid heating from the sun.
The MA350 features more robust weather protection, though it is not completely
weatherproof. While the case itself is rated IP67, necessary penetrations in the enclosure
