Component Locations

A
K
I
J
A Engine exhaust
B Burner exhaust
C Rear support jack (if equipped)
D Fork lift pocket (4 locations)
E Fuel Fill
F Reflector (multiple locations)
G
Power receptacle (120 V, 20 A, GFCI)
Owner's Manual for Indirect Fired Heater
F
G
H
N
Figure 2-3. Exterior Components
B
C
D
E
M
H Engine access door
I Tie-down point (4 locations)
J Control panel access door
K Trailer jack
L Air inlet guard
M Hot air discharge duct
N
Duct storage, thermostat access door
