- Page 1 All manuals and user guides at all-guides.com OPERATING MANUAL ba75541e07 03/2018 P o w IQ S ENSOR MIQ/R6 IQ S SIX CHANNEL RELAY OUTPUT MODULE ENSOR...
- Page 2 All manuals and user guides at all-guides.com MIQ/R6 © Copyright 2018 Xylem Analytics Germany GmbH Printed in Germany. ba75541d07 03/2018...
-
Page 3: Table Of Contents
All manuals and user guides at all-guides.com MIQ/R6 List of contents MIQ/R6 - List of contents Overview ....... 5 1.1 How to use this component operating manual . - Page 4 All manuals and user guides at all-guides.com List of contents MIQ/R6 Indexes ....... 22 7.1 Explanation of the messages .
-
Page 5: Overview
All manuals and user guides at all-guides.com MIQ/R6 Overview Overview How to use this component operating manual Structure of the IQ Sensor Net Operating Manual IQ S ENSOR operating manual System Operating Manual (Ring Binder) Operating Operating Operating Manual Manual Manual IQ Sensor MIQ Module... -
Page 6: Features Of The Miq/R6
All manuals and user guides at all-guides.com Overview MIQ/R6 Features of the MIQ/R6 General The MIQ/R6 output module has six relay outputs. You can link relay outputs to characteristics sensors. The linked relay outputs can be used to monitor sensors or to output measured values. -
Page 7: Safety Instructions
All manuals and user guides at all-guides.com MIQ/R6 Safety instructions Safety instructions Safety information 2.1.1 Safety information in the operating manual This operating manual provides important information on the safe operation of the product. Read this operating manual thoroughly and make yourself familiar with the product before putting it into operation or working with it. -
Page 8: Safe Operation
All manuals and user guides at all-guides.com Safety instructions MIQ/R6 Safe operation 2.2.1 Authorized use The authorized use of the MIQ/R6 consists of providing relay outputs in the IQ S . Only the operation and running according to the instructions ENSOR and technical specifications given in this operating manual is authorized (see chapter 6 T... -
Page 9: Installation
All manuals and user guides at all-guides.com MIQ/R6 Installation Installation Scope of delivery MIQ module Accessory set, including: – 4 x cable glands (clamping range 4.5-10 mm) with seals and blind plugs – 4 x ISO blind nuts M4 with suitable cheese-head screws and plain wash- –... -
Page 10: Installation In The Iq Sensor Net
All manuals and user guides at all-guides.com Installation MIQ/R6 – Temperature resistance (minimum and maximum temperature) – Stability against UV light when used outdoors – Protection against water and dust (Nema or IP protection class). Suitable fusing of the electrical circuit –... -
Page 11: Electrical Connections: General Instructions
All manuals and user guides at all-guides.com MIQ/R6 Installation Electrical connections: General instructions Cable glands All electric cables are fed from below via prepared openings in the enclosure of the MIQ/R6. Cable glands with different clamping ranges are included with the MIQ/R6 to provide sealing between the cable and enclosure as well as for strain relief. - Page 12 All manuals and user guides at all-guides.com Installation MIQ/R6 them to the terminal strip Any wires that are not used and project into the enclosure must be cut off as closely as possible to the cable gland. Screw a small cable gland with sealing ring into each remaining free opening and close it with a blind plug.
-
Page 13: Connections To The Relay Outputs
All manuals and user guides at all-guides.com MIQ/R6 Installation Connections to the relay outputs WARNING If external electrical circuits that are subject to the danger of physical contact are incorrectly connected to the relay contacts, there may be a danger of life threatening electric shock. - Page 14 All manuals and user guides at all-guides.com Installation MIQ/R6 Connecting lines Open the module. to the terminal strip 240 VAC 240 VAC 240 VAC 240 VAC 240 VAC 240 VAC 2 A AC 2 A AC 2 A AC 2 A AC 2 A AC 2 A AC SENSORNET 2...
- Page 15 All manuals and user guides at all-guides.com MIQ/R6 Installation Close the module. ba75541d07 03/2018...
-
Page 16: Settings
All manuals and user guides at all-guides.com Settings MIQ/R6 Settings The MIQ/R6 module has six relay outputs. Relay outputs operate as openers (normally closed) or closers (normally open). On the IQ S terminal, you can ENSOR assign a name to the outputs. ... -
Page 17: Maintenance And Cleaning
All manuals and user guides at all-guides.com MIQ/R6 Maintenance and cleaning Maintenance and cleaning Maintenance The MIQ/R6 requires no special maintenance. The general maintenance of IQ S components is described in the IQ S system ENSOR ENSOR operating manual. Cleaning The cleaning of IQ S components is described in the IQ S ENSOR... -
Page 18: Technical Data
All manuals and user guides at all-guides.com Technical data MIQ/R6 Technical data General data Dimensions 144.0 52.2 Front view: Side view: 115.0 11.0 70.0 16.5 Rear view: Stack mounting: Fig. 6-1 Dimension drawing of MIQ module (dimensions in mm) Mechanical Maximum number of structure MIQ modules in a mod-... - Page 19 All manuals and user guides at all-guides.com MIQ/R6 Technical data Weight Approx. 0.5 kg Type of protection IP 67 (not suitable for conduit connection). Cable glands Suitable for cable 4.5 - 10 mm or sheath diameter 9.0 - 13 mm Ambient Temperature conditions...
-
Page 20: Miq/R6
All manuals and user guides at all-guides.com Technical data MIQ/R6 MIQ/R6 Electrical data Nominal voltage Max. 24 VDC via the IQ S (for ENSOR details, see the T chapter of ECHNICAL DATA the IQ S system operating ENSOR manual) Power consumption 1.5 W Protective class Overvoltage... - Page 21 All manuals and user guides at all-guides.com MIQ/R6 Technical data Relay functions – System monitoring – Sensor monitoring – Limit indicator – Frequency output – Pulse-width output – Cleaning – Sensor-controlled – Manual control – Alarm contact ba75541d07 03/2018...
- Page 22 All manuals and user guides at all-guides.com Indexes MIQ/R6 Indexes Explanation of the messages In this chapter you will find a list with all the message codes and corresponding message texts that may occur in the log book of the IQ S system for ENSOR the MIQ/R6 output module.
- Page 23 All manuals and user guides at all-guides.com...
- Page 24 For more information on how Xylem can help you, go to xyleminc.com. ® Service address: Xylem Analytics Germany Sales GmbH &...
