ST STEVAL-IFP042V1 User Manual

Industrial digital output expansion board based on ISO808A in TFQFPN32
Introduction
The STEVAL-IFP042V1 is an industrial digital output expansion board based on
provides a powerful and flexible environment for the evaluation of the driving and diagnostic capabilities of the
high-side smart power solid state relay, with embedded galvanic isolation and 20 MHz SPI control interface, in a digital output
module connected to 0.7 A industrial loads.
The STEVAL-IFP042V1 directly interfaces with the microcontroller on the
connectors, ensuring connectivity with either a
The galvanic isolation between the microcontroller and the process stage is guaranteed by the ISO808A.
It is also possible to evaluate a 16 channel digital output system enabling the daisy chaining feature on two
stacked expansion boards.
UM3136 - Rev 1 - October 2023
For further information contact your local STMicroelectronics sales office.
NUCLEO-F401RE or a
Figure 1. STEVAL-IFP042V1 expansion board
ISO808A and compatible with
STM32 Nucleo driven by GPIO pins and Arduino® R3
NUCLEO-G431RB development board.
UM3136
User manual
package
STM32 Nucleo. It
ISO808A octal
STEVAL-IFP042V1
www.st.com
