ST STEVAL-IFP045V1 User Manual

Getting started with STEVAL-IFP045V1 industrial digital output expansion board
Introduction
The STEVAL-IFP045V1 is an industrial digital output expansion board. It provides a powerful and flexible environment for the
evaluation of the driving and diagnostic capabilities of the
output module connected to 2.5 A industrial loads.
The STEVAL-IFP045V1 can interface with the microcontroller on the
and Arduino R3 connectors.
The expansion board can be connected to either a
It is also possible to evaluate a system composed of up to four stacked
As an example, a system with four
module.
UM3057 - Rev 1 - August 2022
For further information contact your local STMicroelectronics sales office.
IPS1025HQ
NUCLEO-F401RE
STEVAL-IFP045V1 expansion boards allows you to evaluate a quad channel digital output
Figure 1. STEVAL-IFP045V1 expansion board
single high-side smart power solid state relay, in a digital
STM32 Nucleo via 5 kV optocouplers driven by GPIO pins
or a NUCLEO-G431RB development board.
STEVAL-IFP045V1 expansion boards.
