Unit Operation
2. Testing
After cuff inflation, air will slowly rise as indicated by the corresponding cuff pressure
value. A flashing " " will appear simultaneously on screen signaling heart beat
detection.
Note: Keep relaxed during testing. Avoid speaking or moving body parts.
3. Result Display
The screen will display measurements for systolic and diastolic blood pressure with
voice broadcast. An indicator representing the current measurement will appear next to
the corresponding WHO Classification.
Note: Refer to Page 24~25 for detail WHO Blood Pressure Classification Information.
Unit Operation
Last 3 Tests Average
With power off, press the "MEM" button to activate screen display. After the unit performs
a self-diagnosis ,The LCD screen will display the average of the last three measurements of the
current memory group. The " AVG " symbol will appear along with the corresponding
WHO Blood Pressure Indicator. The Memory Check mode can be accessed by
pressing "MEM" button. If looking at the average of other memory groups, set the memory group
you want to view before entering the mean view state. (See "Select Memory Group" on Page 12)
Memory Check
You may check past test results by using the "MEM" button. The
most recent test result and oldest test result in memory can be viewed by pressing
and holding the "MEM" button. Upon activating test results. you can press the "MEM"
button to scroll through all test results stored in memory. To check the memory test results from
other groups, please press corresponding "GROUP1" button or "GROUP2" button.
15 Unit Operation
Irregular Heartbeat Indicator
If the monitor detects an irregular heart rhythm two or more times during the measuring
process, the Irregular Heartbeat Symbol "
measurement results. Irregular heartbeat rhythm is defined as rhythm that is either 25%
slower or faster than the average rhythm detected while measuring systolic blood pressure
and diastolic blood pressure. Consult your physician if the Irregular Heartbeat Symbol
" " frequently appears with your test results.

Power Off

The " START/STOP " button can be pressed to turn off the unit in any mode. The unit can
turn off the power itself about 3 minutes no operation in any mode.
Safety Precaution: If pressure in arm cuff becomes too extreme while testing,
press the " START/STOP " button to turn power off. The cuff pressure will rapidly
dissipate once the unit is off.
Arm Shake Indicator
If there is arm movement during the measurement, the "
measurement results may be inaccurate, and the situation will be recorded at the end of the
measurement as a reminder.
Cuff loose Indicator
When starting the measurement, "
When the cuff is too loose, "
and start measuring again.
17 Unit Operation

Memory Deletion

Memory for a selected group may be deleted while in Memory Check mode. Press and hold
the " GROUP1 " button or " GROUP2 " button for approximately 3 seconds to delete all
memory records from the selected group with voice broadcast "Memory Clear" and then transfer
into testing mode. Press the "START/STOP " button to turn the unit off.
Note: Memory cannot be recovered once it has been deleted.

Low Battery Indicator

The unit will broadcast "Low Battery" when battery life is depleting and unable to inflate cuff for
testing. The " " appears simultaneously for approximately 5 seconds prior to shutting
off. Replace batteries at this time. No memory loss will occur throughout this process.
"appears on screen along with
" icon may flash. Indicates that the
"will be displayed when the cuff is properly wound.
OK
"will be displayed. At this time, please wear the cuff correctly
