Unit Operation

System Settings

With power off, press "GROUP1" button or
The Memory Group icon flashes.
1. Select Memory Group
While in the System Setting mode, you may accumulate test results into 2 different
groups. This allows 2 different users to save individual test results Press " MEM " button to
choose a group setting. Test results will automatically store in each selected group.
2. Time/Date setting
Press "GROUP1" button or "GROUP2" button
first by adjusting the "MEM" button.
Press "GROUP1" button or "GROUP2" button
setting the dat, hour and minute in the same way. Every time the
"GROUP2" button is pressed, it will lock in your selection and continue in succession
( month,day,hour, minute,12/24 hours)
Unit Operation

Applying the Arm Cuff

1. Firmly insert air plug into opening located on left side of monitor unit.
2. With sticky nylon section facing outward, insert end of cuff underneath metal ring
of cuff .
3. Fasten cuff about 1-2cm (0.4-0.8'') above the elbow joint. For best results apply cuff to
bare arm and keep level with heart while testing
Note: Do not insert air plug into opening located on back side of monitor unit.
This opening is designed for an optional power supply only.
"GROUP2" button to activate System Settings.
again to set the Time/Date mode. Set the year
again to confirm current month. Continue
"GROUP1" button or
.
11 Unit Operation
3. Time Format setting
Press "GROUP1" button or "GROUP2" button
Set the time format by adjusting the"MEM" button. EU means European Time
US means U.S Time.
4.Voice Setting
Press "GROUP1" button or "GROUP2" button
ON or OFF by pressing the "MEM" button.
5.Volume Setting
Press "GROUP1" button or "GROUP2" button to enter volume setting mode. Set the voice volume
by adjusting the "MEM" button . There are six volume levels.
6. Saved Settings
While in any setting mode, press " START/STOP " button to turn the unit off. All
information will be saved.
Note: If unit is left on and not in use for 3 minutes, it will automatically save all information
and shut off.
13 Unit Operation

Testing

1. Power On
Press and hold "START/STOP" button to turn the unit on. The LCD screen will appear full
for one second as unit performs a quick diagnosis. A voice tone will indicate when unit is
ready for testing.
Note: Unit will not function if residual air from previous testing is present in cuff.
The LCD will flash "
again to set the time format setting mode.
to enter voice setting mode. Set voice format
" until pressure is stabilized.
