Testing; Power Off - JOYTECH DBP-1359b Owner's Manual

Unit Operation

Testing

1. Power On
Press and hold " " button to turn the unit on. The LCD screen will appear
for one second as unit performs a quick diagnosis. A voice tone will indicate when unit is
ready for testing.
Note: Unit will not function if residual air from previous testing is present in cuff.
The LCD will flash " " until pressure is stabilized.
Unit Operation
3. Testing
After cuff inflation, air will slowly subside as indicated by the corresponding cuff pressure
value. A flashing " " will appear simultaneously on screen signaling heart beat
detection.
/
Note: Keep relaxed during testing. Avoid speaking or moving body parts.
4. Result Display
The screen will display measurements for systolic and diastolic blood pressure with
voice broadcast. An indicator representing the current measurement will appear next
to the corresponding WHO Classification.
Indicator
Note: Refer to Page 23~24 for detail WHO Blood Pressure
15
17
mmHg
mmHg
/
Classification Information.
Unit Operation
2. Pressurization
The unit will automatically inflate to the proper shelf and stop inflating. During this time,
please keep quiet.
/
Note: Pressurization will gradually subside and ultimately stop when cuff is not
properly applied to the arm. If this occurs, press"
to turn the unit off.
Unit Operation
Irregular Heartbeat Indicator
If the monitor detects an irregular heart rhythm two or more times during the measuring
process, the Irregular Heartbeat Symbol "
measurement results. Irregular heartbeat rhythm is defined as rhythm that is either 25%
slower or faster than the average rhythm detected while measuring systolic blood pressure
and diastolic blood pressure. Consult your physician if the Irregular Heartbeat Symbol
" " frequently appears with your test results.
5. Deleting/Storing Test Results
User may delete their current test result due to unfavorable testing conditions or for any
other reason. To delete the last test result, press the "SET" button after result is displayed.
If result is not deleted, it will automatically store by date within the previously configured
Memory Group.
Note: Be sure the appropriate Memory Group selection is made prior to testing.
If the number of tests surpasses the allotted 60 memories per group, the most recent tests
will appear first, thus eliminating the oldest readings.

Power Off

The " " button can be pressed to turn off the unit in any mode. The unit can
turn off the power itself about 3 minutes no operation in any mode.
Safety Precaution: If pressure in arm cuff becomes too extreme while testing,
press the " " button to turn power off. The cuff pressure will rapidly
dissipate once the unit is off.
16
mmHg
"button
18
"appears on screen along with
