Maintenance

1. Avoid dropping, slamming, or throwing the unit.
2. Avoid extreme temperatures. Do not expose unit directly under sunshine.
3. When cleaning the unit, use a soft fabric and lightly wipe with mild detergent.
Use a damp cloth to remove dirt and excess detergent.

Specifications

Product Description Arm-type Fully Automatic Blood Pressure Monitor
DBP-6281L
Model
Display LCD Digital Display Size:94mm x 90.6mm（3.7" x 3.57"）
Measurement Method Oscillometric Method
Systolic Pressure
Diastolic Pressure
Pressure
Measurement Range
Pressure
Pulse
Pulse
Pressurization Automatic Pressurization
Memory 2x150 Memories in Two Groups with Date and Time
Irregular Heartbeat Detection
WHO Classification Indicator
Last 3 Tests Average
Function
Low Battery Detection
Automatic Power-Off
Voice
Backlight
Bluetooth
Lithium battery 3.7 V or DC5.0v 1000mA medical external power
supply (DC5.0V, 1000mA)(Optional,If users want to purchase other
Power Source
adapters, they need to meet the requirements of IEC 60601-1 )
Battery Life Approximately 2 months at 3 tests per day
Unit Weight Approx.297g (10.48 oz) (excluding battery)
Approx.155.5mm X 108.5mm X 75mm（6.12" x 4.27" x 2.95"）
Unit Dimensions
Approx.135 (W) x 485(L) mm
Cuff Circumference
(Medium cuff: Fits arm circumference 22-36 cm)
29
60mmHg～260mmHg
40mmHg～200mmHg
0mmHg～299mmHg
±3mmHg
30 ~ 180 Beats/Minute
±5%
27 Maintenance
4. Cuff Cleaning: Do not soak cuff in water! Apply a small amount of rubbing alcohol to
a soft cloth to clean cuff's surface. Use a damp cloth (water-based) to wipe clean.
Allow cuff to dry naturally at room temperature. The cuff must be cleaned and disinfected
before use between different users.
5. Do not use petrol, thinners or similar solvents.
6. Remove batteries when not in operation for an extended period of time.
7. Do not disassemble product.
8. It is recommended the performance should be checked every 2 years.
9. Expected service life: Approximately three years at 10 tests per day.
10.No service and maintenance while it is in use and maintenance only be performed by service
personnel. Service and maintenance require parts, repair, technical support will be provided.
Specifications
Temperature
Humidity
Operating Environment
Pressure
Temperature:
Storage Environment
Humidity
Internal Powered Equipment,Type BF
Classification:
Ingress Protection
IP21, Indoor Use Only
Rating:
Modulation Type
Version
Bluetooth Operation frequency 2.4GHz(2400~ 2483.5MHz)
Antenna gain
Bandwidth
Specifications are subject to change without notice.
Safety Standard(included but not limited):
1. IEC 80601-2-30, medical electrical equipment - part 2-30: particular requirements
for the basic safety and essential performance of automated noninvasive
sphygmomanometers. (Cardiovascular)
2. ISO 81060-2, non-invasive sphygmomanometers - part 2: clinical validation of
automated measurement type. (Cardiovascular)
3. AAMI / ANSI ES 60601-1:2005/(R)2012 and C1:2009/(R)2012 and,
a2:2010/(r)2012 (consolidated text) medical electrical equipment -- part 1: general
requirements for basic safety and essential performance
4. AAMI/ANSI/IEC 60601-1-2, Medical Electrical Equipment -- Part 1-2: General
Requirements For Basic Safety And Essential Performance -- Collateral Standard:
Electromagnetic Disturbances -- Requirements And Tests (General II (ES/EMC)).
5. IEC 60601-1-11, medical electrical equipment - part 1-11: general requirements
for basic safety and essential performance - collateral standard: requirements for medical
electrical equipment and medical electrical systems used in the home healthcare
environment.
℃ ℉ ℉
1 ~ 40 (50 ~104 )
0℃
15% ~ 93%RH
800hPa~1060hPa
℉ ℉
℃ ℃
-25 ~55 (-13 ~131 )
≤93% RH
,Cuff is the Applied Part
GFSK
5.0.1 BT Signal mode
0 dBi
2.0 MHz
28
30
