Hardware Supplied - Mocka Archie Assembly Instructions Manual

Archie
Bookcase
A B
dowel screw
x12 x4
V
safety
strap x1
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall
anchor with all furniture sold and we recommend these are used to prevent your product tipping.
The fixing device provided should fit most wall types, but please note that different wall materials
may require different fixing devices from those supplied.
mocka.co.nz I mocka.com.au
C D
bolt locking
x8 nut x8

HARDWARE SUPPLIED

W X
screw wall
x 1 anchor x 1
WALL STRAP
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
E
wedge screw
x8
Y
wall
screw x 1
Phillips & Flathead screwdrivers
and hammer required
F G
plastic
x8 glide x4
Z
washer
x 2
